Quick Details
-
Place of Origin:
-
China
-
Product name:
-
Filter Element
-
Application:
-
Industrial filter
-
Material:
-
Stainless Steel Fiber Sintered Felt and Stainless Steel Woven Mesh
-
Size:
-
Custom size
-
Feature:
-
Large filter area, strong dirt holding capacity and strong reusability
-
Shape:
-
Cylinder Shape
-
Working temperature:
-
<300℃
-
Length:
-
5,10,20,30,40 inch and other special sized
-
Certificate:
-
ISO9001:2008
Quick Details
-
Weight (KG):
-
1
-
Marketing Type:
-
Hot Product 2022
-
Core Components:
-
None
-
Place of Origin:
-
China
-
Product name:
-
Filter Element
-
Application:
-
Industrial filter
-
Material:
-
Stainless Steel Fiber Sintered Felt and Stainless Steel Woven Mesh
-
Size:
-
Custom size
-
Feature:
-
Large filter area, strong dirt holding capacity and strong reusability
-
Shape:
-
Cylinder Shape
-
Working temperature:
-
<300℃
-
Length:
-
5,10,20,30,40 inch and other special sized
-
Certificate:
-
ISO9001:2008
Products Description
|
Filter media
|
Wire mesh and sintered fiber felt of 304, 316, 316L, 317L, 904L, Monel, Hastelloy, etc.
|
|
||
|
PH range
|
1-14
|
|
||
|
Working temperature
|
-50℃ - 800℃
|
|
||
|
Working pressure
|
30Mpa
|
|
||
|
Micron rating
|
1-300um
|
|
||
|
Diameter
|
25 40 50 60 100 mm, customize provided
|
|
||
|
Lenth
|
5 10 20 30 40 inches, customize provided
|
|
||
|
Thickness
|
2mm, customize provided
|
|
||
|
Connectors
|
Standard interface(222,220,226), threaded connection, fast interface connection, flange connection, tire rod, special customized interface connection.
|
|
||
|
Application
|
Screening, classifying, filtration, separating of plastic fiber and polymer fiber
melt filtration and chemical fluid filtration. |
|
||
|
Properties
|
High strength, corrosion resistance, good air permeability, large filtration area, high particle holding capability, easy washing and backwashing, accurate filtering.
|
|
||
Advantages:
1. Good air permeability and filtration performance, and able to filter particles 3-100um steadily.
2. High porosity rate, large filtration area and particle holding capacity.
3. Suitable to work under the environment of high temperature/pressure, over-lower temperature; excellent resistance to erosion or abrasion.
4. Reusing possible after being washed by ultrasonic wave, chemical reagent ,etc.
Application:
1. High polymer industry: synthetic, plastic or film production.
2. Chemical industry: petrochemical, petroleum /paint refining, etc.
3. Pharmaceutical and food industry: medicine/food refining or cycling.
4. Mechanical and vessel industries: hydraulic machine/milling oil production, gas flow controlling.
5. Air purification or water treatment: sterilization&filtration.
