- Product Details
- {{item.text}}
Quick Details
-
Spindle Bore(mm):
-
0
-
Width of bed (mm):
-
0 mm
-
Spindle Motor Power(kW):
-
55
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Z Axis)(mm):
-
1350 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
4.0x3.8x4.9m
-
Brand Name:
-
Sealion
-
Model Number:
-
CQ5825
-
Weight (KG):
-
28000
-
Model:
-
CQ5825
-
After-sales Service Provided:
-
support
-
After-sales Service:
-
support
-
Functions:
-
multiple functions
-
Brand:
-
Sealion
Quick Details
-
Type:
-
VERTICAL
-
Max. Length of Workpiece (mm):
-
1600
-
Max. Spindle Speed (r.p.m):
-
150 r.p.m
-
Spindle Bore(mm):
-
0
-
Width of bed (mm):
-
0 mm
-
Spindle Motor Power(kW):
-
55
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Z Axis)(mm):
-
1350 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
4.0x3.8x4.9m
-
Brand Name:
-
Sealion
-
Model Number:
-
CQ5825
-
Weight (KG):
-
28000
-
Model:
-
CQ5825
-
After-sales Service Provided:
-
support
-
After-sales Service:
-
support
-
Functions:
-
multiple functions
-
Brand:
-
Sealion
|
Model No
|
CQ5825
|
|
Max Machining Diameter (mm)
|
2500
|
|
Max Machining Height (mm)
|
1400
|
|
Max Machining Weight (Kg)
|
6300
|
|
Max Cutting Force (N)
|
35000
|
|
Max Swivel Torque (N.m)
|
33000
|
|
Table Size (mm)
|
2000
|
|
Main Motor(Table) Power (Kw)
|
55
|
|
Table Rotary Speed (r/min)
|
2.5~80
|
|
Horizontal Travel of Tool Post (mm) -X
|
1300
|
|
Vertical Travel of Tool Post (mm) -Z
|
1350
|
|
Max Swivel Angle of Tool Post
|
+/-30°
|
|
Feeding Speed of Tool Post (mm/min)
|
0.5~3000
|
|
Power of X/Z axis Motor (Kw) *
|
2
|
|
Torque of X/Z axis Motor (N.m)
|
9.4
|
|
Positioning Accuracy of X&Z aixs (mm/1000mm)
|
+/-0.03
|
|
Max Size of Tool Bar (mm*mm)
|
40x50
|
|
Travel of Cross Beam (mm)
|
/
|
|
Speed of Cross Beam Movement (mm/min)
|
/
|
|
Total Weight of Machine (Kg)
|
28000
|
|
Size of Machine L*W*H (m)
|
4.0x3.8x4.9
|
Q:
Do you have CE certificate?
A:
Yes , we have CE certification, machine quality is guaranteed.
Q:
What is your payment terms ?
A:
30% down-payment after contract ,and 70% payment before shipment, Meanwhite it can be discussed according to your situation.
Q:
what is your delivery time ?
A:
The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.
Q:
Can we pay by L/C or others ?
A:
Yes ,you can make the payment by T/T , l/C etc.
Q:
What is the warranty period ?
A:
The warranty period is general 13 monthes after B/L date. During the warranty period, we will provide free replacement parts (EXW) which are easy damaged.
Q:
Can you send the service engineer to our company ?
A:
When the machine arrive the destination, we timely send service engineers to install machine according to buyer's schedule, the buyer shall bear all expenses.
Q:
what to do if the product encounters quality issues?
A:
Please contact our customer service personnel in a timely manner and provide relevant product photos and detailed descriptions. We will provide you with after-sales service as soon as possible.
