Quick Details
-
Warranty:
-
3years
-
Brand Name:
-
Flagsun
-
Model Number:
-
FSP-010W
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
350*300*23mm
-
Certificate:
-
CE, CB, ISO
Quick Details
-
Cell size:
-
156mm*156mm
-
Type:
-
Flexible
-
Panel Efficiency:
-
15%
-
Warranty:
-
3years
-
Brand Name:
-
Flagsun
-
Model Number:
-
FSP-010W
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
350*300*23mm
-
Certificate:
-
CE, CB, ISO
Product Description
|
Electrical Characteristics
|
|
|
Module No.
|
FSP-010W
|
|
Maximum Power at STC (Pmax)
|
10W
|
|
Optimum Operating Voltage (Vmp)
|
17.8 V
|
|
Optimum Operating Current (Imp)
|
0.47 A
|
|
Open-Circuit Voltage (Voc)
|
21.6 V
|
|
Short-Circuit Current (Isc)
|
0.62 A
|
|
Module Efficiency
|
14.80%
|
|
Power Tolerance
|
0~+3%
|
|
Operating Module Temperature
|
-40 ℃ to +85 ℃
|
|
Maximum System Voltage
|
1000V
|
|
Maximum Series Fuse Rating
|
10A
|
|
Mechanical Characteristics
|
|
|
Solar Cells
|
Poly-crystalline
|
|
Dimensions
|
350*300*23mm
|
|
Weight
|
0.75 kg
|
|
Front Cover Glass
|
Tempered glass
|
|
Cable
|
4mm², 90cm
|
|
Connector
|
MC4 Compatible/ USB output
|
|
Temperature Characteristics
|
|
|
Nominal Operating Cell Temperature (NOCT)
|
45℃ ± 2 ℃
|
|
Temperature Coefficient of Pmax
|
- 0.45 %/ºC
|
|
Temperature Coefficient of Voc
|
- 0.35 %/ºC
|
|
Temperature Coefficient of Isc
|
0.065±0.015 %/ºC
|
