Quick Details
-
Weight (KG):
-
1 kg
-
Model Number::
-
PES water filter
-
Filter Type::
-
water filter
-
Filter Media:
-
Asymmetric PES Membrane
-
Support Layers:
-
Polypropylene
-
Micron Rating(um):
-
0.04, 0.1, 0.2, 0.45, 0.65, 0.85, 1.2
-
Outer Cage, End Cap,Inner Core:
-
Reinforced Polypropylene
-
O-Rings/Gaskets::
-
Silicone, Nitrile, EPDM, Viton,
-
Length(Based On DOE End Cap):
-
10"- 254mm, 20"- 508mm, 30"-762 mm, 40"- 1016mm
-
Normal Flow Direction:
-
4.2 bar (60.9 psi) at 25C (77 F )
-
PH Value Compatibility:
-
2-13
Quick Details
-
Core Components:
-
filter
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
TS Filter
-
Weight (KG):
-
1 kg
-
Model Number::
-
PES water filter
-
Filter Type::
-
water filter
-
Filter Media:
-
Asymmetric PES Membrane
-
Support Layers:
-
Polypropylene
-
Micron Rating(um):
-
0.04, 0.1, 0.2, 0.45, 0.65, 0.85, 1.2
-
Outer Cage, End Cap,Inner Core:
-
Reinforced Polypropylene
-
O-Rings/Gaskets::
-
Silicone, Nitrile, EPDM, Viton,
-
Length(Based On DOE End Cap):
-
10"- 254mm, 20"- 508mm, 30"-762 mm, 40"- 1016mm
-
Normal Flow Direction:
-
4.2 bar (60.9 psi) at 25C (77 F )
-
PH Value Compatibility:
-
2-13
Products Description
PARAMETER INFORMATION
|
Materials Of Construction |
Filter Media
|
Asymmetric PES Membrane
|
|
|
Support Layers
|
Polypropylene
|
|
|
Micron Rating
|
0.04, 0.1, 0.2, 0.45, 0.65, 0.85, 1.2 um
|
|
|
Inner Core
|
Reinforced Polypropylene
|
|
|
Outer Cage, End Cap
|
Reinforced Polypropylene
|
|
|
Seal Method
|
Thermal Bonded, No Adhesives
|
|
|
O-Rings/Gaskets:
|
Silicone, Nitrile, EPDM, Viton, Teflon
|
|
Cartridge Dimensions |
Outer Diameter
|
69mm(2.75'')
|
|
|
Inner Diameter
|
33mm(1.30'')
|
|
|
Length(Based On DOE End Cap)
|
10”, 20”, 30”, 40”
|
|
|
Filtration Area(m2)
|
0.65 m2 per 10''
|
|
Operating Conditions |
Normal Operating Temperature
|
Up to 60℃ (140 ℉ )
|
|
|
Max.operating Temperature
|
85℃ (185 ℉ ) at △ P£1.0 bar (14.5psi)
|
|
|
Normal Flow Direction
|
4.2 bar (60.9 psi) at 25℃ (77 ℉ )
|
|
|
Reverse Flow direction
|
2.1 bar (30.5psi) at 25℃ (77 ℉ )
|
|
|
PH Value Compatibility
|
2-13
|
|
|
Sterilization
|
Steam Sterilization for 30 minutes at 121± 2 ℃ , Cumulative Time: 8 hours
|
|
Cartridge Safety
|
Endotoxin
|
＜ 0.25 EU/ml
|
|
|
Extractables
|
0.03g / 10"
|
|
GRADE
|
PRODUCT
|
MICRON
|
END CAP
|
LENGTH
|
O-RING / GASKET
|
|
F-FOOD & BEVERAGE
|
IPS
|
004-0.04um
|
AA- DOE
|
10-10"
|
S-silicone; N-nitrile
|
|
P-PHARMACEUTICAL
|
|
010-0.1um
|
CN-226/FIN
|
20-20"
|
E-epdm ; T-teflon (encaptulated)
|
|
C-CHEMICAL
|
|
020-0.2um
|
BN-222/FIN
|
30-30"
|
V-viton
|
|
E-ELECTRONICS
|
|
045-0.45um
|
BF-222/ FLAT SEAL
|
40-40"
|
How to Order?- Example
|
