Quick Details
-
Engine Brand:
-
HONDA
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
storike
-
Dimension(L*W*H):
-
1980*930*2125 MM
-
Drum diameter:
-
560 MM
-
Exciting Force:
-
22KN
-
Engine:
-
HONDA GX390/BRIGGS&STRATTON /CHANGCHAI 192F
-
Engine type:
-
gasoline/ diesel
-
Output power (KW):
-
9.7
-
Lubricating oil volume(L):
-
1.1
-
Drive mode:
-
double-wheel series, parallel motor
-
Steering mode:
-
Hydraulic cylinder, articulated steering
-
Steering system:
-
Swing articulated
-
Vibration wheel:
-
Front
-
Drive form:
-
Hydraulic Motors
-
Water spray form:
-
Intermittent pressure water spray
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
9.7KW
-
Weight:
-
1.2 TON
-
Engine Brand:
-
HONDA
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
storike
-
Dimension(L*W*H):
-
1980*930*2125 MM
-
Drum diameter:
-
560 MM
-
Exciting Force:
-
22KN
-
Engine:
-
HONDA GX390/BRIGGS&STRATTON /CHANGCHAI 192F
-
Engine type:
-
gasoline/ diesel
-
Output power (KW):
-
9.7
-
Lubricating oil volume(L):
-
1.1
-
Drive mode:
-
double-wheel series, parallel motor
-
Steering mode:
-
Hydraulic cylinder, articulated steering
-
Steering system:
-
Swing articulated
-
Vibration wheel:
-
Front
-
Drive form:
-
Hydraulic Motors
-
Water spray form:
-
Intermittent pressure water spray
Construction Machinery Hydraulic Road Roller 1 ton 3 ton 5 ton Double Drum Roller Compactor
Shandong Storike Engineering & Mechanism Co., Ltd is specialized in the sales and production of small road roller, compact ram, mobile lighting car, hydraulic power station, troweling machine and other construction machine. Our products are widely used in municipal and highway pavement road roller maintenance, small area compacting and depressed trough compacting building and construction materials such as all kinds of non-cohesive materials, sandy soil, gravels, sand-macadam mixtures, stabilized soil, bituminous concrete, etc. Especially it is most economical for foundation treatment of country road, large community road, water conservancy construction and real estate development and backfill compaction of other mini-type projects.
1.We use the famous brand engine, like Honda, Changchai. Also can be equipped the engine with EPA certification.
2.We use the famous brand pump and motor. The pump use the brand Sauer, the motor use the brand Danfoss.
3.Our road roller passed CE, SGS and ISO9001 certification.
| MODEL | ST1200 | WALKING CHARACTERISTICS | |
| WEIGHT | Speed | 0-4km/h | |
| Operating Weight | 1180kg | Theoretical Climbing Ability | 30% |
| SIZE | BRAKE | ||
| Working Width | 915mm | Working Brake | Variable displacement pump |
| Overall Length | 1885/1880mm | STEERING | |
| Machine Height | 1450/1985mm | Steering Mode | Hydraulic Steering |
| Turning Radius(outer) | 2800mm | Steering System | Swing Articulated |
| Width of Wheel | 800mm | EXCITATION SYSTEM | |
| Wheel Diameter | 500mm | Vibration Steel Wheel | Before |
| Track | 1280mm | Drive Form | Hydraulic motors |
| DRIVE | Vibration Frequency | 65hz | |
| Engine Manufacturer | CHANGCHAI | Vibration Amplitude | 0.5mm |
| Engine Model | 192F | Exciting Force | 20kn |
| Engine Type | Single cylinder Air cooling Four stroke | SPRINKLER SYSTEM | |
| Number of Cylinders | 1 | Water Spray Form | Gravity-type water |
| Output Power | 8.1kw | CAPACITY | |
| Rotating Speed | 3600rpm | Hydraulic Oil Capacity | 18L |
| Electrical Equipment | 12v | Fuel Capacity | 5.5L |
| Drive Mode | Variable displacement pump | Water Tank Capacity | 65L |
1.The machine is equipped with the brand power,brand-name quality assurance,superior performance,easy to start.
2.The machine is selected of international brand-name Hydraulic variable pump and quantitative mator,continuously variable,it can walk backward and forward.
3.It has Hydraulic steering,steering light and flexible.
4.It has completed control function,to fully control the machine running at any time.
5.It uses the Japanese-made Nsk(seiko)bearings ,to ensure the machine's performance.
6.It is installed of luxury seats,easy adjustment,comfortable work.
7.It has streamlined body design,more beautiful and generous.
8.The machine's surface is treated by spray.
9. The product has passed CE certification.
According to your detail requirement, please find the road roller you really need.
1.Optional diesel engine or gasoline engine.
2.Single drum walk behind road rollers.
3.Double drum walk behind road rollers.
4.Ride-on small vibrating road roller.
5.Full hydraulic ride on road rollers.
6.Big drum road rollers with the cabin.
7.Static drum/sheep foot drum/rubber drum rollers.
8.Customized according to your requirements.
Our products are u sed in municipal, highway pavement maintenance operations,
also apply to groove, pipe trench backfill compaction in the construction engineering, building construction and square homework, rolling lawns, etc.
Hot Sales 300 KG to 8 Ton Road Rollers walk behind road roller ride on road roller single drum road roller double drum road roller 330 kg walk behind road roller 550kg walk behind double mini road roller 800KG walking type hydraulic road roller 800KG ride on road roller 1 ton road roller 1.2 ton hydraulic road roller 2 ton road roller 3 ton road roller 4 ton asphalt rollers 5 ton roller compactor 8 ton road roller
