Quick Details
-
Engine Brand:
-
TOP BRAND
-
Grade Ability:
-
±33°
-
Place of Origin:
-
China
-
Brand Name:
-
SEM
-
Dimension(L*W*H):
-
6200*2340*3200mm
-
Exciting Force:
-
507N/cm
-
Model:
-
SEM522
-
Emission:
-
TIER II
-
Rated Speed:
-
2,000r/min
-
Static Pressure:
-
507N/cm
-
Steering Angle:
-
±33°
-
Swing Angle:
-
±12°
-
Hydraulic Oil Tank Volume:
-
80L
-
Freqency-Hi/Lo:
-
30/28HZ
-
Amplitude-Hi/Lo:
-
2/1mm
-
Excitation Force (High/Low):
-
374/215kN
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
140KW
-
Weight:
-
22,000kg
-
Engine Brand:
-
TOP BRAND
-
Grade Ability:
-
±33°
-
Place of Origin:
-
China
-
Brand Name:
-
SEM
-
Dimension(L*W*H):
-
6200*2340*3200mm
-
Exciting Force:
-
507N/cm
-
Model:
-
SEM522
-
Emission:
-
TIER II
-
Rated Speed:
-
2,000r/min
-
Static Pressure:
-
507N/cm
-
Steering Angle:
-
±33°
-
Swing Angle:
-
±12°
-
Hydraulic Oil Tank Volume:
-
80L
-
Freqency-Hi/Lo:
-
30/28HZ
-
Amplitude-Hi/Lo:
-
2/1mm
-
Excitation Force (High/Low):
-
374/215kN
Contact way
Carlota Ji Sales Manager
Phone/Skype/Whatsapp: +86-18637752754
Email: carlota@oriemac.com
Phone/Skype/Whatsapp: +86-18637752754
Email: carlota@oriemac.com
Product features
Product Description:
High efficiency: Unique structure of vibration unit and drum, 50 mm size and provide excellent sealing
performance Reliability: Vibration system with eccentric vibration frame design, extended service life of up to 50%.
performance Reliability: Vibration system with eccentric vibration frame design, extended service life of up to 50%.
Maintenance:
Counter timer and monitoring system three-state control system.
Counter timer and monitoring system three-state control system.
Applications
* Fields of application - Soil compaction in the construction of roads and railways, runways and industrial sites
* Can be equipped with a complete set of rollers with diamond cams for compacting clay
* With square CAM rollers for sealing sand production efficiency
Specifications
|
Model
|
SEM522
|
|
Std Rated Power-Gross
|
140 kW
|
|
Rated Speed
|
2,000 r/min
|
|
Operating Weight
|
22,000 kg
|
|
Fuel Tank Volume
|
262 L
|
|
Max. Grade Ability w/o vibbration
|
34%
|
|
Turning Radius Inside Drum Edge
|
6,350 mm
|
|
Static Pressure
|
507 N/cm
|
|
Steering Angle
|
±33 °
|
|
Swing Angle
|
±12 °
|
|
F/R I
|
2.98 km/h
|
|
F/R II
|
5.88 km/h
|
|
F/R III
|
9.60 km/h
|
|
Hydraulic Oil Tank Volume
|
80 L
|
|
Freqency-Hi/Lo
|
30/28 HZ
|
|
Amplitude-Hi/Lo
|
2/1 mm
|
|
Excitation Force (High/Low)
|
374/215 kN
|
|
Drum Width
|
2,130 mm
|
|
Drum Diameter
|
1,600 mm
|
|
Drum Thickness
|
50 mm
|
|
Tires Type
|
20.5-25
|
