Quick Details
-
Ice storage capacity:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ICESTA
-
Dimension(L*W*H):
-
1800*1000*1350/Depends
-
Weight:
-
990 KG
-
Name:
-
Block ice making machines
-
Certification:
-
ce
Quick Details
-
Ice Shape:
-
ICE BLOCK
-
Voltage:
-
380V/3P/50Hz
-
Power:
-
17.9KW ~ 97.6KW
-
Ice storage capacity:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ICESTA
-
Dimension(L*W*H):
-
1800*1000*1350/Depends
-
Weight:
-
990 KG
-
Name:
-
Block ice making machines
-
Certification:
-
ce
ICESTA Commercial Block ice making machines Brine refrigeration system
Icesta block ice machines adapt famous name brand components,like Germany Bitzer compressor, Korea vibration obsorber tube, Danfoss valves, Schneider electrics, Korea LG PLC or Germany Siemens PLC and touch screen, definitely make sure the robust quality of machine.
|
Model Parameters |
IB2T-R2W |
IB3T-R2W |
IB5T-R2W |
IB10T-R2W |
|
|
20ft |
20ft |
40ft |
40ft |
|
Compressor Model |
4TES-9 |
4JE-15 |
6HE-28 |
6HE-28*2 |
|
Design capacity |
2 000kg/24h |
3 000kg/24h |
5 000kg/24h |
10 000kg/24h |
|
Refrigeration capacity |
17.9 kW |
27.4 kW |
48.8 kW |
97.6 kW |
|
Evaporating temp. |
- 15 ℃ |
- 15 ℃ |
- 15 ℃ |
- 15 ℃ |
|
Condensing temp. |
40 ℃ |
40 ℃ |
40 ℃ |
40 ℃ |
|
Total input |
9.13 kW |
15.27 kW |
27.85 kW |
50.5 kW |
|
Power of compressor |
6.7 kW |
11.9 kW |
18.6 kW |
18.6*2 kW |
|
W ater pump of cooling tower |
0.75 kW |
1.5 kW |
2.2 kW |
5.5 kW |
|
Power of cooling fan |
0.18 kW |
0.37 kW |
0.75 kW |
1. 5 kW |
|
Water pump input |
1.1 kW |
1.1 kW |
2.2 kW |
2.2 kW |
|
Power of electric hoist |
0.4kW |
0.4kW |
0.4kW |
0.4kW |
|
Agitator |
|
|
3.7 kW |
3.7 kW |
|
Power supply |
380 V/3P/ 5 0Hz |
|||
|
Water feeding pressure |
0.1Mpa - 0.5Mpa |
|||
|
Refrigerant |
R 22 |
|||
|
Design ambient temp. |
30 ℃ |
|||
|
Design water inlet temp. |
2 0 ℃ |
|||
|
Ice temp. |
-10 ℃ |
|||
|
Each weight of the block ice |
25 kg |
|||
|
Dimension of ice |
390*120*600 |
|||
|
Each freezing time |
11 h |
11 h |
11 h |
11 h |
|
Each doff ice time |
0. 4 h |
0. 4 h |
0.5h |
0.8 h |
|
Ice Machine Diameter |
1800*1000*1350 |
1800*1000*1350 |
2050*1000*1370 |
2160*1400*1940 |
|
Dimension of cooling tower |
φ920*1830 |
φ1165*1645 |
φ1385*2150 |
φ1880*2120 |
|
Unit weight |
5.5t |
6t |
7.5t |
9t |
|
Unit Operating Weight |
9t |
10t |
13t |
16t |
Block ice structure
Block ice machine
