Quick Details
-
CRI (Ra>):
-
80
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
LL-T/600-CW/120P-3C-B01
-
Brand Name:
-
Lowcled
-
Input Voltage(V):
-
AC175-265V(50/60Hz)
-
Working Lifetime(Hour):
-
50000
-
Lamp Luminous Flux(lm):
-
4580
-
Application:
-
Office
-
Lamp Body Material:
-
Aluminum+PC
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
130
-
IP Rating:
-
IP20
-
Warranty(Year):
-
2-Year
-
CRI (Ra>):
-
80
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
LL-T/600-CW/120P-3C-B01
-
Brand Name:
-
Lowcled
-
Input Voltage(V):
-
AC175-265V(50/60Hz)
-
Working Lifetime(Hour):
-
50000
-
Lamp Luminous Flux(lm):
-
4580
-
Application:
-
Office
-
Lamp Body Material:
-
Aluminum+PC
Product Description
* 130lm/w luminous efficacy.
* High quality aluminum material with high conductivity
* Soft and no flickering through special optical design, which is more comfortable in using.
* High reliable, the lifespan could reach over 50000hours, which is 8-12 times of traditional fluorescent tube, almost
maintenance free.
* Environmentally-friendly, Safe pollution-free, reach ROHS requirement.
* High quality aluminum material with high conductivity
* Soft and no flickering through special optical design, which is more comfortable in using.
* High reliable, the lifespan could reach over 50000hours, which is 8-12 times of traditional fluorescent tube, almost
maintenance free.
* Environmentally-friendly, Safe pollution-free, reach ROHS requirement.
|
Model
|
Length
|
Color
|
LED Type
|
LED qty.
|
Luminosity
|
PF
|
Ra
|
Power
|
Input voltage
|
|
LL-T/600-WW/120P-3C-B01
|
600mm
|
Warm White
|
SMD2835
|
120PCS
|
2106LM
|
>0.9
|
80
|
18W
|
175-265VAC
|
|
LL-T/600-CW/120P-3C-B01
|
600mm
|
Cool White
|
SMD2835
|
120PCS
|
2340LM
|
>0.9
|
80
|
18W
|
175-265VAC
|
|
|
|
|
|
|
|
|
|
|
|
|
LL-T/1200-WW/240P-3C-B01
|
1200mm
|
Warm White
|
SMD2835
|
240PCS
|
4212LM
|
>0.9
|
80
|
36W
|
175-265VAC
|
|
LL-T/1200-CW/240P-3C-B01
|
1200mm
|
Cool White
|
SMD2835
|
240PCS
|
4680LM
|
>0.9
|
80
|
36W
|
175-265VAC
|
Product Presentation
|
Model
|
L(mm)
|
W(mm)
|
H (mm)
|
|
LL-T/600-120P-3C-B01
|
600
|
74
|
24
|
|
LL-T/1200-240P-3C-B01
|
1200
|
74
|
24
|
1. High quality SMD2835 LED chipset.
2. Solid state, high shock/vibration resistant.
3. Universal input voltage AC175-265V.
4. Power factor is >0.9.
5. Quick and easy installation to minimize retrofit cost.
6. No mercury and other hazardous materials, fully RoHS compliant.
7. High cost-effective.
8. Completely insulated electrical design for maximum safety.
2. Solid state, high shock/vibration resistant.
3. Universal input voltage AC175-265V.
4. Power factor is >0.9.
5. Quick and easy installation to minimize retrofit cost.
6. No mercury and other hazardous materials, fully RoHS compliant.
7. High cost-effective.
8. Completely insulated electrical design for maximum safety.
|
Model
|
LL-T/600-120P-3C-B01
|
LL-T/1200-240P-3C-B01
|
|
|
Power（±10%）
|
18W
|
36W
|
|
|
Input(Frequency)
|
AC 175-265V（50/60Hz）
|
|
|
|
Output Voltage
|
DC70-150V
|
|
|
|
PF
|
>0.9
|
|
|
|
LED Qty (SMD2835)/PCS
|
120
|
240
|
|
|
Lumen（±10%）Lm
|
2340lm
|
4680lm
|
|
|
CCT(K)
|
2800-6500K
|
|
|
|
CIR(Ra)
|
>80
|
|
|
|
Beam angle
|
120°
|
|
|
|
Socket / Diameter
|
2Pin/3Pin
|
|
|
|
Working Temperature
|
-20℃～45℃
|
|
|
|
Humility
|
20%~80%RH
|
|
|
|
Storage Temperature
|
-30℃～60℃
|
|
|
|
Life span of Light Source
|
≧50000 H
|
|
|
|
Material
|
Al+PC
|
|
|
|
Temperature Rise
|
<35℃
|
|
|
|
IP Grade
|
IP20
|
|
|
|
Net Weight
|
273g
|
522g
|
|
Application
Lowcled
LED t
ube light can be extensively applied to general lighting, such as mall, store, hotel, office, supermarket, commercial building, station, bus, warehouse, signage, residential, parking lot, home, restaurant , train, railway, subway station, bank, warehouse, exhibition gallery, library, closet, factory, cabinet, cupboard, kitchen, refrigeration units etc. Replace conventional fluorescent lamp or sodium lamp.
