Quick Details
-
Model Number:
-
A-208
-
Dimension:
-
250mm x 730mm x 480mm
-
Power Supply Mode:
-
Other
-
Storage:
-
-
-
SNR:
-
-
-
Output Power:
-
450W
-
Connection Type:
-
Other
-
Shell Material:
-
Birch Plywood
-
Format:
-
-
-
Product name:
-
Double 8-Inch Linear Array Speaker
-
System type:
-
Double 8-inch linear array
-
Tweeter:
-
44mm voice coil, neodymium magnetic
-
Bass:
-
2x 120mm magnetic steel/49.5 mm voice coil
-
Frequency range:
-
55Hz-20kHz
-
Frequency response:
-
60Hz-18kHz (± 3DB)
-
Sensitivity:
-
105DB SPL 1W/1M input
-
Impedance:
-
8ohms
-
Power rating:
-
450W
-
N.W.:
-
24KG
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Ava
-
Model Number:
-
A-208
-
Dimension:
-
250mm x 730mm x 480mm
-
Power Supply Mode:
-
Other
-
Storage:
-
-
-
SNR:
-
-
-
Output Power:
-
450W
-
Connection Type:
-
Other
-
Shell Material:
-
Birch Plywood
-
Format:
-
-
-
Product name:
-
Double 8-Inch Linear Array Speaker
-
System type:
-
Double 8-inch linear array
-
Tweeter:
-
44mm voice coil, neodymium magnetic
-
Bass:
-
2x 120mm magnetic steel/49.5 mm voice coil
-
Frequency range:
-
55Hz-20kHz
-
Frequency response:
-
60Hz-18kHz (± 3DB)
-
Sensitivity:
-
105DB SPL 1W/1M input
-
Impedance:
-
8ohms
-
Power rating:
-
450W
-
N.W.:
-
24KG
Specification
|
Double 8 Inch Line Array Speaker
|
|
|
|
Model
|
A-208
|
|
|
System type
|
44mm voice coil, neodymium magnetic
|
|
|
Tweeter
|
1 x Sub-D 15pol (Analogue Remote)
|
|
|
Bass
|
2x 120mm magnetic steel/49.5 mm voice coil
|
|
|
Frequency range
|
55Hz-20kHz
|
|
|
Frequency response
|
60Hz-18kHz (± 3DB)
|
|
|
Sensitivity
|
105DB SPL 1W/1M input
|
|
|
Impedance
|
8ohms
|
|
|
Power rating
|
450W
|
|
|
Maximum sound pressure level
|
135dB SPL
|
|
|
Sound field radiation range
|
110 ° X 5 °
|
|
|
Input interface
|
2xNeutrik NL4MP
|
|
|
Box size/Height/width/depth
|
250mm x 730mm x 480mm
|
|
|
N.W
|
23KG
|
|
|
Package size
|
78-35-33cm, 30.2KG
|
|
|
Single 18 Inch Subwoofer
|
|
|
|
Model
|
A-208S
|
|
|
System type
|
Single 18 inch subwoofer
|
|
|
Frequency range
|
40Hz-500Hz
|
|
|
Frequency response
|
50Hz-450Hz(±3dB)
|
|
|
Sensitivity
|
104dB SPL 1w/1m
|
|
|
Impedance
|
8 ohms
|
|
|
Rated power
|
800W
|
|
|
Bass
|
220mm magnetic steel/100mm voice coil, 18mm birch plywood
|
|
|
Maximum sound pressure level
|
136dB SPL
|
|
|
Input interface
|
2xNeutrik NL4MP
|
|
|
Dimension
|
750mm x705mm x 509mm
|
|
|
N.W.
|
45KG
|
|
