Quick Details
-
Model Number:
-
ST-0-103-C04-N006-RS
-
Max. Current:
-
3A
-
Mechanical Life:
-
40000 times or more
-
Specification:
-
3A 125VAC;1.5A 250VAC
-
handle:
-
Brass, chrome plated
-
Shaft sleeve:
-
Brass, nickel or chrome plated
-
Iron shell:
-
Stainless steel
-
Bracket:
-
Brass, tin plated
-
Contact piece/terminal:
-
Copper alloy, silver or gold plated
-
Contact resistance:
-
Less than 20mΩ
-
Withstand voltage:
-
1000VAC, 1 minute
-
Certification:
-
RoHs
Quick Details
-
Max. Voltage:
-
125V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YF
-
Model Number:
-
ST-0-103-C04-N006-RS
-
Max. Current:
-
3A
-
Mechanical Life:
-
40000 times or more
-
Specification:
-
3A 125VAC;1.5A 250VAC
-
handle:
-
Brass, chrome plated
-
Shaft sleeve:
-
Brass, nickel or chrome plated
-
Iron shell:
-
Stainless steel
-
Bracket:
-
Brass, tin plated
-
Contact piece/terminal:
-
Copper alloy, silver or gold plated
-
Contact resistance:
-
Less than 20mΩ
-
Withstand voltage:
-
1000VAC, 1 minute
-
Certification:
-
RoHs
Product Description
|
Specifications
|
|
|
|
Rating
|
3A 125VAC, 1.5A 250VAC
|
|
|
Contact Resistance
|
20MΩ Max
|
|
|
Dielectric Strength
|
1000VAC， 1 Minute
|
|
|
Operatiing Temperature
|
-25ºC~+85ºC
|
|
|
Electrical Life
|
10000 cycles
|
|
|
Mechanical Life
|
40000 cycles
|
|
|
Circuit
|
SPDT
|
|
|
Switch function
|
ON-OFF-ON
|
|
|
Materials:
|
|
|
|
Actuator
|
Brass, Chrome-plated
|
|
|
Bushing
|
Brass, Nickel or chrome-plated
|
|
|
Housing
|
Stainless Steel
|
|
|
Support Bracket
|
Brass,Tin-plated
|
|
|
Contact/Terminals
|
Copper Alloy, Silver or gold-plated
|
|
NOTE: Specifications and Materials listed above are for switches with standard options. For information on specific and custom switches, Please feel free to contact us.
Typical Applications:
• Medical equipment
• Telecommunications
• Instrumentation
• Machinery
Typical Applications:
• Medical equipment
• Telecommunications
• Instrumentation
• Machinery
