Quick Details
-
Power:
-
0.37kw
-
Material:
-
standard seaworthy package, Carbon Steel
-
Product name:
-
smokeless plastic industrial waste incinerator manufacturers
-
Color:
-
/slivery/black/white/customized by clients
-
Capacity:
-
10-500kgs/batch
-
Fuel:
-
Diesel Oil/LPG/Natural gas incinerator
-
Certification:
-
CE,ISO9001,ISO14001,OHSAS18001
-
Service life:
-
10-20 years
-
Function:
-
garbage burning
-
Voltage:
-
380V / 220V
-
Advantage:
-
no smoke, no smell
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TIANLANG
-
Model Number:
-
TLFS
-
Power:
-
0.37kw
-
Material:
-
standard seaworthy package, Carbon Steel
-
Product name:
-
smokeless plastic industrial waste incinerator manufacturers
-
Color:
-
/slivery/black/white/customized by clients
-
Capacity:
-
10-500kgs/batch
-
Fuel:
-
Diesel Oil/LPG/Natural gas incinerator
-
Certification:
-
CE,ISO9001,ISO14001,OHSAS18001
-
Service life:
-
10-20 years
-
Function:
-
garbage burning
-
Voltage:
-
380V / 220V
-
Advantage:
-
no smoke, no smell
There are four chambers, two combustors for friendly environment in waste incinerator. There will be no smoke, no smell, no pollution after be burning.
it was devided into :primary combustion chamber,second combustion chamber,mixture of combustion chamber ,smoke purification chamber and chimney.
- Garbage waste enters the combustion chamber and is fully oxidized and burned to generate flue gas.
- Then the gas will enter second combustion room,burning at high temperatures to completely burn harmful gases
- By subsequent equipment to remove harmful substances such as dust and acid gases
- Finally,the exhausted gas will be no smoke,no smell,no pollution.
Advantage
(1) Gasifiedpyrolysis incineration is used for burning many kinds of waste.
(2) Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust,dioxin etc.
(3) Totally enclosed operation is suitable for treating infectious waste to avoid secondary pollution.
(4) Compact structure and small land occupation.
Technical Data
| Model | TL30 | TL50 | TL150 | TL300 | TL500 |
| Buring Cpacity | 20-30kg/time (3-6 times/day) | 30-50kg/time (3-6 times/day) | 100-150kg/time (3-6times/day) | 200-300kg/time (3-6times/day) | 300-500kg/time (3-6times/day) |
| Incinerator Size m (L*H*B) | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3**2*4.8 |
| Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
|
Chimney External Diameter
(mm)
|
280 | 280 | 300 | 400 | 460 |
| Draught Fan | 0.37kw | 0.37kw | 0.5kw | 1.1kw | 1.1kw or 0.55kw |
| Combustion Improver Device |
0.11kw
|
0.11kw
|
0.11kw
|
0.11kw
|
0.11kw
|
| Re-Burning Device |
0.11 kw
|
0.11 kw
|
0.11 kw
|
0.11 kw
|
0.11 kw
|
| Voltage | 380v or 220v | 380v or 220v | 380v or 220v | 380v or 220v | 380v or 220v |
Package
By standand seaworthy package for medical/animal carcess/industrical waste incinerator
Delivery
