Quick Details
-
Spangle Type:
-
Regular Spangle
-
Hardness:
-
Full Hard
-
Place of Origin:
-
Vietnam
-
Grade:
-
Spcc Secc Dx51d Dx52d Dx53d
Quick Details
-
Type:
-
Steel Sheet
-
Thickness:
-
0.12mm-6mm
-
Coating:
-
Z10-Z29
-
Spangle Type:
-
Regular Spangle
-
Hardness:
-
Full Hard
-
Place of Origin:
-
Vietnam
-
Grade:
-
Spcc Secc Dx51d Dx52d Dx53d
|
Technical Standard
|
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
|
|
Steel Grade |
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD,
S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440,
SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement |
|
Type
|
Coil/Sheet/Plate/Strip
|
|
Thickness
|
0.12-6.00mm,or customer's requirement
|
|
Width
|
600mm-1500mm, according to customer's requirement
|
|
Type of Coating
|
Hot Dipped Galvanized Steel(HDGI)
|
|
Zinc Coating
|
30-275g/m2
|
|
Surface Treatment
|
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
|
|
Surface Structure
|
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
|
|
Quality
|
Approved by SGS,ISO
|
|
ID
|
508mm/610mm
|
|
Coil Weight
|
3-20 metric ton per coil
|
|
Package
|
Water proof paper is inner packing,galvanized steel or coated steel
sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement |
|
Export market
|
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America,
North America, etc
|
Product Introduction
Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer,
thereby combining the substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel
parts first. In order to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned
in an ammonium chloride or zinc chloride aqueous solution or a mixed solution of ammonium chloride
and zinc chloride.And then sent to the hot-dip plating bath. Hot-dip galvanizing has the advantages of
uniform coating, strong adhesion and long service life.
Surface Structure
Product Display
Product Advantages
01.Anticorrosive :13 years in heavy industrial areas,50 years in the ocean,104 years in the suburbs
01.Anticorrosive :13 years in heavy industrial areas,50 years in the ocean,104 years in the suburbs
and 30 years in cities.
02.Cheap: The cost of hot-dip galvanizing is lower than that of other coatings.
03.Reliable: The zinc coating is metallurgically bonded to the steel and forms part of the steel
surface,so the coating is more durable.
04.Strong toughness: The galvanized layer forms a special metallurgical structure that can withstand
mechanical damage during transportation and use.
05.Comprehensive protection: Every part of the plated piece can be galvanized,and is fully protected
02.Cheap: The cost of hot-dip galvanizing is lower than that of other coatings.
03.Reliable: The zinc coating is metallurgically bonded to the steel and forms part of the steel
surface,so the coating is more durable.
04.Strong toughness: The galvanized layer forms a special metallurgical structure that can withstand
mechanical damage during transportation and use.
05.Comprehensive protection: Every part of the plated piece can be galvanized,and is fully protected
even in depressions,sharp corners,and hidden places.
06.Save time and energy: Galvanizing process is faster than other coating methods.
06.Save time and energy: Galvanizing process is faster than other coating methods.
Production Line
Product Application
Packing And Shipping
FAQ
Q:Can you send samples?
A:Of course, we can send samples to all parts of the world, our samples are free, but customers
need to bear the courier costs.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to
purchase.
Q:What are the shipping ports?
A:You can choose other ports according to your needs.
Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.
Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications.
Q:How long does your delivery time take?
A:In general, our delivery time is within 7-45 days, and may be delayed if the demand is
extremely large or special circumstances occur.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging.
Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed
with a fumigation wooden pallet. It can effectively protect products from corrosion
during ocean transportation.
Q:What is your working time?
A:In general, our online service time is: 8:00-22:00, after 22:00, we will reply to your inquiry
during the next working day.
need to bear the courier costs.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to
purchase.
Q:What are the shipping ports?
A:You can choose other ports according to your needs.
Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.
Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications.
Q:How long does your delivery time take?
A:In general, our delivery time is within 7-45 days, and may be delayed if the demand is
extremely large or special circumstances occur.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging.
Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed
with a fumigation wooden pallet. It can effectively protect products from corrosion
during ocean transportation.
Q:What is your working time?
A:In general, our online service time is: 8:00-22:00, after 22:00, we will reply to your inquiry
during the next working day.
