Large flow filling valve, filling flow up to 125ml/s
-When filling,ensure that the filling valve and the can are completely sealed, maintain the isobaric environment, ensure the liquid level is accurate
- 304/316 stainless steel filling pump
- All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean - Efficient spray nozzle rinse thoroughly and save water for flushing
- Product Details
- {{item.text}}
Quick Details
-
Filling Accuracy:
-
2mm
-
Voltage:
-
110V/220/,50HZ/60HZ, 220V/380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinri
-
Dimension(L*W*H):
-
1800*1600*2250
-
Weight:
-
2000 KG
-
Product name:
-
Beer Filling Machine
-
capacity:
-
1000BPH
-
material:
-
SUS304
-
bottle type:
-
glass bottle
-
bottle volume:
-
330ml,500ml
-
After-sales Service Provided:
-
Video Technical Support
-
Processing Types:
-
rinsing filling and capping
-
filling method:
-
isobaric
-
vacumm:
-
once or twice
Quick Details
-
Machinery Capacity:
-
1000BPH
-
Packaging Material:
-
Plastic, Metal, Glass
-
Filling Material:
-
Beer
-
Filling Accuracy:
-
2mm
-
Voltage:
-
110V/220/,50HZ/60HZ, 220V/380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinri
-
Dimension(L*W*H):
-
1800*1600*2250
-
Weight:
-
2000 KG
-
Product name:
-
Beer Filling Machine
-
capacity:
-
1000BPH
-
material:
-
SUS304
-
bottle type:
-
glass bottle
-
bottle volume:
-
330ml,500ml
-
After-sales Service Provided:
-
Video Technical Support
-
Processing Types:
-
rinsing filling and capping
-
filling method:
-
isobaric
-
vacumm:
-
once or twice
Products Description
Zhangjiagang Jinri Packaging Machinery Co., Ltd.
Zhangjiagang Jinri Packaging Machinery Co., Ltd. is a professional manufacturer of beverage machinery in China.Our main products have: Water filling production line, juice filling production line, carbonated drinks filling production line, and also aerosol filling machine, 5 Gallon bottle filling production line, and all other auxiliary equipment. Our engineers are located all over the world and can provide safe and fast service to your beverage production solutions in your country.
Details Images
Beer Filling Machine
The machine is advanced filling and capping equipment, it’s designed on the basis of absorbing domestic and foreign advanced technology. It can be widely used in the filling and sealing of CSD drinks, beer, energy drink,soft drinks, cola and sparkling wine, etc. The containers can be aluminum cans, tin cans and PET cans.It has such advantages as advanced construction, stable working, convenient operation, as well as high production efficiency to satisfy the techniques of the CSD drink production.
Can Stacker.
1-PLC control of the whole machine, fully automatic operation;-Adapt to various stack types and bottle types
2-Segmented transmission with high-quality conveyor chain, the output section can be arbitrarily lengthened
3-Using 304 material, the whole machine is beautiful and elegant
2-Segmented transmission with high-quality conveyor chain, the output section can be arbitrarily lengthened
3-Using 304 material, the whole machine is beautiful and elegant
Slide Type Empty Tank Spray Washer.
-Scope of application: water spraying and drying on the slope of the tin can.
-water spraying box made by stainless steel structure.
-the built-in ￠32 mm stainless steel spray pipe, divide into two segments, hot and cold water tank temperature higher than 85 degrees.
-tank cage, by ￠article 8 mm stainless steel.
-water spraying box made by stainless steel structure.
-the built-in ￠32 mm stainless steel spray pipe, divide into two segments, hot and cold water tank temperature higher than 85 degrees.
-tank cage, by ￠article 8 mm stainless steel.
New type filling valve
New type sealing machine
- Capping effect is stable and reliable
- Better sealing effect
- All 304/316 stainless steel construction
-
No bottle no capping
- Automatic stop when lack of bottle
Flat Conveyor.
- Energy saving. High efficient. Adapt to customer factory layout
- Special lubrication system, keep products clean, health, safety
- Extended service life
- Special lubrication system, keep products clean, health, safety
- Extended service life
pasteurization tunnel
- Electric eyes design keep whole line running safety and quickly
- Overload protection mechanism to effectively ensure the safety of the machine
- Overload protection mechanism to effectively ensure the safety of the machine
|
Model
|
Filling
heads
|
Capping
heads
|
Capaclty
(BPH)
|
Motor
power(KW)
|
Dimension(mm)
|
Weight(kg)
|
|
4YDL4-4-1
|
4
|
1
|
1000
|
2.2
|
2000*700*2250
|
2300
|
|
YDL12-1
|
12
|
1
|
1500
|
2.2
|
2500*1800*2300
|
3500
|
|
YDL12-4
|
12
|
4
|
4000
|
3
|
2800*2100*2300
|
5100
|
|
YDL18-4
|
18
|
4
|
9000
|
3
|
3500*2200*2300
|
7300
|
|
YDL20-4
|
20
|
4
|
12000
|
3
|
4700*2800*2050
|
9600
|
|
YDL30-6
|
30
|
6
|
16000
|
4
|
5460*3300*2700
|
12500
|
|
YDL40-6
|
40
|
6
|
20000
|
5.5
|
5556*4239*2950
|
16200
|
Can Lines.
A complete can filling line solution from Jinri Machine takes into account every step of your tin aluminum PET can carbonated soft drink process, from minimising resource waste to determining your bottle's ideal look and weight. With everything centred around one supplier, you get wide-ranging expertise, line equipment and ongoing services. This ensures high quality and efficiency from packaging to equipment, fast ramp-up and beyond.
A complete can filling line solution from Jinri Machine takes into account every step of your tin aluminum PET can carbonated soft drink process, from minimising resource waste to determining your bottle's ideal look and weight. With everything centred around one supplier, you get wide-ranging expertise, line equipment and ongoing services. This ensures high quality and efficiency from packaging to equipment, fast ramp-up and beyond.
