Quick Details
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
3850*2070*2260 mm
-
Weight:
-
1650 KG
-
Feed amount:
-
2.2kg/s
-
Engine power:
-
35 HP/ 25.74 kW
-
Pure Productivity:
-
1.8-4 Acre/h
Quick Details
-
Number of Rows:
-
4
-
Working Width(mm):
-
1500 mm
-
Tractor Power(HP):
-
1 - 35 HP
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
3850*2070*2260 mm
-
Weight:
-
1650 KG
-
Feed amount:
-
2.2kg/s
-
Engine power:
-
35 HP/ 25.74 kW
-
Pure Productivity:
-
1.8-4 Acre/h
Contact Way
Agricultural Machinery Crawler-Type Sugarcane Harvester As60t
Product Overview
1.Suitable for working on slope below 10and field over 1.5m sugarcane planting row spacing; 2.Flexible floating crawler chassis,
the left and right tracks can independenty float up and down according to the ground conditions, and the complex fields are highly
adaptable, low ground pressure imposed, and the protection effect of the ratoon is good;
3.Three section bended conveyor, quick release structure that straight and bend type can be easily con- verted according to
requirements to adapt to different truck height and ensure uniform unloading
4.6 cylinder high pressure common rail Cummins engine with strong power, low fuel consumption and reliable performance;
5.Front feed roller is driven by two hydraulic motor, enhanced cane grabbing ability;, optimized conveying roller with new teeth
surface, cane feeding, leaves and trash removing ability is largely increased;
6.Extractor is driven by one independent hydraulic motors; direction can be freely adjusted by 180° step- lessly; enlarged
extractor and optimized structure ensure that impurities are better blown to the ground and the effect of impurity removal is
better;
7.The machine frame adopts a new generation of patented technology, increasing the space of sugar- cane discharge, which can
effectively solve the problem of harvesting clogging under the condition of high yield of sugarcane.
the left and right tracks can independenty float up and down according to the ground conditions, and the complex fields are highly
adaptable, low ground pressure imposed, and the protection effect of the ratoon is good;
3.Three section bended conveyor, quick release structure that straight and bend type can be easily con- verted according to
requirements to adapt to different truck height and ensure uniform unloading
4.6 cylinder high pressure common rail Cummins engine with strong power, low fuel consumption and reliable performance;
5.Front feed roller is driven by two hydraulic motor, enhanced cane grabbing ability;, optimized conveying roller with new teeth
surface, cane feeding, leaves and trash removing ability is largely increased;
6.Extractor is driven by one independent hydraulic motors; direction can be freely adjusted by 180° step- lessly; enlarged
extractor and optimized structure ensure that impurities are better blown to the ground and the effect of impurity removal is
better;
7.The machine frame adopts a new generation of patented technology, increasing the space of sugar- cane discharge, which can
effectively solve the problem of harvesting clogging under the condition of high yield of sugarcane.
Product Paramenters
|
Mode
|
|
Unit
|
AS60T
|
|
|
Harvester
|
Size(L×W×H)
|
mm
|
11700×2300×4960
|
|
|
|
Weight
|
kg
|
15140
|
|
|
Engine
|
Engine brand
|
/
|
Imported QSB 7
|
|
|
|
Engine type
|
/
|
In-line 6 cylinder
|
|
|
|
Displacement
|
L
|
6.7L
|
|
|
|
Power
|
kW
|
169kW/230hp
|
|
|
|
Rotation speed
|
r/min
|
2050
|
|
|
Driving
|
Specifications of crawler belts
|
mm
|
171 × 50 × 600
(Pitch × Pitch number × Crawler Width) |
|
|
|
Track-center distance
|
mm
|
1700
|
|
|
|
Track wheelbase
|
mm
|
3400
|
|
|
|
Driving speed
|
km/h
|
0~10
|
|
|
|
Ground clearance
|
mm
|
530
|
|
|
|
Ground pressure
|
Kpa
|
35
|
|
|
Adaptability
|
Suitable ridge spacing
|
mm
|
1500
|
|
|
|
Suitable ridge height
|
mm
|
100~500
|
|
|
|
Suitable slope
|
%
|
≤10
|
|
|
Performance |
Feeding capacity
|
kg/s
|
>6
|
|
|
|
Net work hour productivity
|
t/h
|
≥15
|
|
|
|
Loss rate
|
%
|
≤7
|
|
|
|
Impurity rate
|
%
|
≤8
|
|
|
|
Sugarcane acceptability
|
%
|
≥90
|
|
|
Others
|
Diesel tank capacity
|
L
|
220L
|
|
|
|
Hydraulic oil capacity
|
L
|
200L
|
|
Product Configuration
