Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
SDJK
-
Showroom Location:
-
No
-
Key words:
-
mini crane
-
Keyword:
-
mini spider crane
-
Color:
-
Customized Color Acceptable
-
Package size per unit product:
-
5600.00cm * 900.00cm * 1000.00cm
-
Specification:
-
0.8- 10 ton
-
Walking Way:
-
Hydraulic Motor
Quick Details
-
Weight (KG):
-
4000
-
Application:
-
Knuckle Boom Crane: Offshore work, Jetty, Deck, Building Construction, Glass Curtain Wall
-
Rated Loading Capacity:
-
1.2-12Ton
-
Place of Origin:
-
China
-
Brand Name:
-
SDJK
-
Showroom Location:
-
No
-
Key words:
-
mini crane
-
Keyword:
-
mini spider crane
-
Color:
-
Customized Color Acceptable
-
Package size per unit product:
-
5600.00cm * 900.00cm * 1000.00cm
-
Specification:
-
0.8- 10 ton
-
Walking Way:
-
Hydraulic Motor
Welcome to SDJK Machinery Manufacturer
We specialize in the production of crawler cranes, spider cranes of various models and tonnages for you to choose, we provide
OEM/ODM services
Welcome to consult us
|
Model
|
|
JKZ30
|
|
|
Specification
|
|
3t
|
|
|
Maximum Working Radius
|
|
8.83m×0.15t
|
|
|
Maximum above-ground head
|
|
9.9m×0.7t
|
|
|
Maximum underground head
|
|
10m×1t(4rope) 20m×1t(2rope) 40m×0.74t(1rope)
|
|
|
Winch Device
|
Hook Speed
|
0-8m/min(4 rope)
|
|
|
|
Rope diameter
|
φ8×45m
|
|
|
Telescopic system
|
Boom Type
|
5 section boom, Pentagonal structure, two sections can be extended independently
|
|
|
|
Boom Length/Time
|
3.1m-9.9m/20sec
|
|
|
Up and down
|
Boom Angle/Time
|
0°~75°/13sec
|
|
|
Slew system
|
Slew Angle/Speed
|
* 0-360°continuous/60sec
|
|
|
Outrigger
|
Outrigger Active Form
|
Manual spin out + oil pressure automatic support (two section outrigger)
|
|
|
|
Maximum Extended Dimensions
|
4530×4370×3700mm
|
|
|
Traction system
|
Walking Way
|
Hydraulic motor drives,two speed
|
|
|
|
Walking Speed
|
0~2.5km/h
|
|
|
|
Traction device
|
Synthetic rubber
|
|
|
|
Grade Ability
|
(20°)36%
|
|
|
Motor
|
Voltage
|
AC 380V
|
|
|
Engine
|
Manufacturer
|
UPOO
|
|
|
|
Type/discharge
|
2V 80/F195
|
|
|
|
Starting Method
|
Electric starting
|
|
|
|
Starting performance
|
-5°C~40°C
|
|
|
|
Fuel/volume
|
Diesel/8L
|
|
|
|
Battery capacity
|
12V 45AH
|
|
|
|
Fuel consumption rate
|
274g/KW-h
|
|
|
|
Noise grade
|
rated speed<81.5dBA(1m)
|
|
|
|
Emission standard
|
National-2 standard
|
|
|
Operating system
|
Operation type (Boom/outrigger)
|
Manual operation, manual walking
|
|
|
|
Operating characteristics
|
Manual operation,remote control
|
|
|
Transport parameters
|
L×W×H
|
2950×980×1560(mm)
|
|
|
|
Total weight
|
2500kg
|
|
