Quick Details
-
Brand Name:
-
RUNZHOU
-
Application:
-
FTTH FTTB FTTX Network
-
Product name:
-
GEPON ONU
-
Service Function:
-
64 full range VLAN ID
-
RF frequency:
-
45~875MHz
-
Wavelength:
-
EPON T*1310nm, EPON R* 1490nm, CATV 1550nm
-
PON interface:
-
1 EPON interface, SC single-mode/single-fiber, symmetric 1.25Gbps
-
Optical interface:
-
SC/PC connector
-
DC power supply:
-
+12V, external AC-DC power adaptor
-
RX sensitivity:
-
< -25dBm @ 1490nm
-
CATV interface:
-
SCTE F type
Quick Details
-
Type:
-
ONU
-
Model Number:
-
RX8102WT
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
RUNZHOU
-
Application:
-
FTTH FTTB FTTX Network
-
Product name:
-
GEPON ONU
-
Service Function:
-
64 full range VLAN ID
-
RF frequency:
-
45~875MHz
-
Wavelength:
-
EPON T*1310nm, EPON R* 1490nm, CATV 1550nm
-
PON interface:
-
1 EPON interface, SC single-mode/single-fiber, symmetric 1.25Gbps
-
Optical interface:
-
SC/PC connector
-
DC power supply:
-
+12V, external AC-DC power adaptor
-
RX sensitivity:
-
< -25dBm @ 1490nm
-
CATV interface:
-
SCTE F type
Products Description
Specification
|
Technical items
|
Description
|
|
PON interface
|
1 EPON interface, SC single-mode/single-fiber, symmetric 1.25Gbps
|
|
Wavelength
|
EPON Tx 1310nm, EPON Rx 1490nm, CATV 1550nm
|
|
Optical interface
|
SC/PC connector
|
|
RX sensitivity
|
< -25dBm @ 1490nm
|
|
CATV interface
|
SCTE F type
|
|
WLAN
|
Compliant with IEEE802.11b/g/n, 300Mbps,
2T2R One internal antenna and one external antenna |
|
LAN interface
|
1x 10/100/1000Mbps + 1x 10/100Mbps auto adaptive Ethernet interfaces, Full Duplex / Half Duplex, AUTO-MDIX, RJ45 connectors
|
|
Indicators
|
11 indicators, for status of power supply, PON, LAN , POTS and CATV .
|
|
DC power supply
|
+12V, external AC-DC power adaptor
|
|
Power consumption
|
≤12W
|
|
Operating condition
|
Operating temp: -5~+55℃
Operating humidity:10~90%(non-condensed) |
|
Storing condition
|
Storing temp: -30~+60℃
Storing humidity:10~90%(non-condensed) |
|
Net weight
|
0.45Kg
|
1. Special Features:
1. Plug and play, integrated auto detecting, auto configuration, and auto firmware upgrade technology.
2. Full compliance to IEEE 802.3ah specification & OAM function.
3. Support 802.11n 2T2R speed up to 300Mbps.
4. Support No-auth, WEP, WPA-PSK and WPA2-PSK function with AES, TKIP encryption.
5. Support rich VLAN, DHCP Server and IGMP snooping multicast feature.
6. Advantage traffic management
7. Advanced Dynamic Bandwidth Allocation (DBA)
8. The WAN port supports bridge / router mode.
9. Advanced L2 features QinQ VLAN & QoS support.
10. Support NAT, Firewall function.
11. RF Video Output Bandwidth (MHz):45~1000, AGC Dynamic Range(dBm):-6~+2
12. Support Console/ Telnet/ NMS management interface for ease of operation and maintenance.
13. Support 2K MAC address table.
14. Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.Data Service
2. Full compliance to IEEE 802.3ah specification & OAM function.
3. Support 802.11n 2T2R speed up to 300Mbps.
4. Support No-auth, WEP, WPA-PSK and WPA2-PSK function with AES, TKIP encryption.
5. Support rich VLAN, DHCP Server and IGMP snooping multicast feature.
6. Advantage traffic management
7. Advanced Dynamic Bandwidth Allocation (DBA)
8. The WAN port supports bridge / router mode.
9. Advanced L2 features QinQ VLAN & QoS support.
10. Support NAT, Firewall function.
11. RF Video Output Bandwidth (MHz):45~1000, AGC Dynamic Range(dBm):-6~+2
12. Support Console/ Telnet/ NMS management interface for ease of operation and maintenance.
13. Support 2K MAC address table.
14. Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.Data Service
2. Functions:
1. Full speed non-blocking switching.
2. 2K MAC address table.
3. 64 full range VLAN ID.
4. Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.
5. Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.
6. Support auto polarity detection of Ethernet ports (AUTO MDIX).
7. Integrated IEEE802.1p QoS with four level priority queues.
8. Support IPv4 IGMP snooping and IPv6 MLD snooping.
9. Support bridge, router and bridge/router mixed mode.
3. WIFI Service Functions:
1. Integrated 802.11b/g/n, 300Mbps, 2T2R.
2. Support 128 connections.
3. Support WEP and WPA/WPA2 security protocols.
4. CATV Service Functions:
1. RF frequency: 45~875MHz.
2. Turn on/off RF output remotely.
1. Full speed non-blocking switching.
2. 2K MAC address table.
3. 64 full range VLAN ID.
4. Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.
5. Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.
6. Support auto polarity detection of Ethernet ports (AUTO MDIX).
7. Integrated IEEE802.1p QoS with four level priority queues.
8. Support IPv4 IGMP snooping and IPv6 MLD snooping.
9. Support bridge, router and bridge/router mixed mode.
3. WIFI Service Functions:
1. Integrated 802.11b/g/n, 300Mbps, 2T2R.
2. Support 128 connections.
3. Support WEP and WPA/WPA2 security protocols.
4. CATV Service Functions:
1. RF frequency: 45~875MHz.
2. Turn on/off RF output remotely.
