Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Changsheng
-
Model Number:
-
500# JDB 303835
-
Bush types:
-
Graphite filled/Solid Lubricant
-
Features:
-
Good Wear Performance
-
Color:
-
Yellow
-
Standard:
-
ISO/TS16949
-
Name:
-
Injection molding machine Bush
-
Application:
-
Plastic Industries
-
Size:
-
30*38*35 mm
-
Lubricating:
-
Graphite
-
Product name:
-
Water Engineering Bearing
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining, Loaders
-
Type:
-
sleeve
-
Material:
-
Bronze + Graphite
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Changsheng
-
Model Number:
-
500# JDB 303835
-
Bush types:
-
Graphite filled/Solid Lubricant
-
Features:
-
Good Wear Performance
-
Color:
-
Yellow
-
Standard:
-
ISO/TS16949
-
Name:
-
Injection molding machine Bush
-
Application:
-
Plastic Industries
-
Size:
-
30*38*35 mm
-
Lubricating:
-
Graphite
-
Product name:
-
Water Engineering Bearing
Self-lubricating Bronze Bushing For Automotive Injection molding machine Bush Water Engineering Bearing
Among those professional CuZn25Al6Mn4Fe3 solid lubricant inlaid bearing 500#-1 manufacturers in China, welcome to buy customized and low price CuZn25 Al 6 Mn 4Fe3 solid lubricant inlaid bearing 500#-1 or get its free sample from our factory.
Self-lubricating Bronze Bushing For Automotive Injection molding machine Bush Water Engineering Bearing
STRUCTURE: Bronze bearings made of CuZn25Al6Mn4Fe3 with solid lubricant plug (graphite)
TECHNICAL DATA:
| Density |
8.0 g/cm3 |
|
|
Hardness |
>210 HB |
|
|
Tensile strength |
>750 N/mm2 |
|
|
Yeild strength |
>450 N/mm2 |
|
|
Elongation |
>8 |
|
|
Coefficient of linear expansion |
1.9x10-5/°C |
|
|
Operating temperature |
-40°C~+300°C |
|
|
Max. Dynamic Load |
120 |
|
|
Max. Speed |
Dry |
0.4 m/s |
|
Oil |
1.0 m/s |
|
|
Max. PV limit |
Dry |
1.5 N/mm2.m/s |
|
Oil |
3.25 N/mm2.m/s |
|
|
Friction |
Dry |
0.12~0.16 μ |
|
Oil |
0.03~0.08 μ |
|
CHARACTERISTICS:
-
Bronze alloy bearings with graphite plugs provide both good wear resistance and great self lubricating feature of this bearing.
-
This designation enables the bearings to be operated without oiling or greasing maintenance.
-
It is widely used in the field of high load and intermittent movement as well as oscillating movement conditions.
TYPICAL APPLICATIONS: Self-lubricating Bronze Bushing For Automotive Injection molding machine Bush Water Engineering Bearing is widely applied in automobile assembling line, water turbine, gate dams, plastic injection machinery etc. Depending on different working conditions, variety of types of different alloys are available from Changsheng Bearing Factory.
