Quick Details
-
Brand Name:
-
SCNTTC
-
Dimension(L*W*H):
-
6058*2438*2591mm
-
Weight:
-
8000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Online support
-
Certification:
-
ISO
Quick Details
-
Capacity:
-
24.5m3
-
Max Working Pressure(MPa):
-
2.2 MPa
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
SCNTTC
-
Dimension(L*W*H):
-
6058*2438*2591mm
-
Weight:
-
8000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Online support
-
Certification:
-
ISO
Geometric Volume 24.5m3 T50 ISO 20 Feet LNG Cryogenic Tank Container
| Product name | 20 Feet T50 ISO Cryogenic Tank Container |
| Design specification |
1. GB150 Pressure Vessel
2. JB/T4784 Supervision Regulation on Safety Technology for Transportable Pressure Vessel |
| Geometric volume | 24.5m³ |
| Working pressure | 2.2Mpa |
| Design temperature | -30~+50℃ |
| Filling medium | LPG,butene |
| Tank material | Q345R |
| Tank weight | 8000Kg |
| Max. filling weight | 34000Kg |
| Overall size | 6058*2438*2591mm |
World class range of technical solutions and services
§ Design and Engineering Consultancy for Cryogenic Installations and Turnkey solutions
§ Establishment of single, multiple, specialty, calibration gases manufacturing facility. This includes laboratory establishment as well as training to the operators at one of the Group Companies having ISO 9001, 14001 and 18001 accreditation.
§ Design and implementation of Purging solutions for various applications like equipment purging, blanketing, cross country pipeline purging, back up blanketing systems.
Figure Photos
