Quick Details
-
Rated current:
-
10-32A
-
Rated voltage:
-
DC 1000V
-
Certificate:
-
CE TUV
-
Material:
-
ABS
-
Color:
-
White
-
Life expectancy:
-
20000 Times
-
Installation Method:
-
Din Rail
-
Guarantee Period:
-
2 year
-
Pole:
-
3P/4P
Quick Details
-
Max. Voltage:
-
DC 1000V
-
Place of Origin:
-
Zhejiang, China
-
Type:
-
Disconnector Main Switch
-
Rated current:
-
10-32A
-
Rated voltage:
-
DC 1000V
-
Certificate:
-
CE TUV
-
Material:
-
ABS
-
Color:
-
White
-
Life expectancy:
-
20000 Times
-
Installation Method:
-
Din Rail
-
Guarantee Period:
-
2 year
-
Pole:
-
3P/4P
Din rail mounting
Extremely short power shut off time of opprox. 3m
2 poles and 4 poles available
IEC60947-3 standard
DC 21 B:16A/25A/32A up to 1500V DC
|
Product Type:
|
Main Switch
|
|
Current:
|
16A-32A
|
|
Voltage:
|
DC 1500V
|
|
Standard:
|
IEC60947-3
|
|
Certificate:
|
CE/TUV/IEC/ROHS
|
|
Color:
|
White
|
Generally speaking, the voltage on DC side of PV system usually is higher, could be as high as 1000VDC. So we need switchgear of Ue=1000VDC. The branch circuit in combiner box needs protection, while the main circuit equipments in combiner box and DC cabinet need isolating function.
1. DIN Rail Mounting Type solar DC Isolator switch with load of 1000VDC or remote operation function. In addition, it needs to install switchgear.
2. On DC side of inverter cabinet to switch with loads, plays a role of isolation for overhauling. DC Isolator switch with MC4 connector.
3.DC Isolator switch with MC4 connector. SISO-32 DIN Rail Mounting Type Solar Isolator Switch / PV Isolator / DC Isolator.
