Quick Details
-
Poles:
-
2P, 3P-24P
-
Pitch:
-
5.0mm/5.08mm
-
Standard:
-
UL, IEC
-
Voltage Rating:
-
300V/250V
-
Current Rating:
-
20A-20A
-
Wire range:
-
26-12AWG/0.5-2.5m㎡
-
Withstanding Voltage:
-
AC2000V/Min
-
Ambient temperature:
-
-40 centigrade~+105 centigrade
-
Pin header:
-
Brass, Tin Plated
-
Housing:
-
PA66.UL94V-0
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Xinlaiya
-
Model Number:
-
XY300-5.0
-
Poles:
-
2P, 3P-24P
-
Pitch:
-
5.0mm/5.08mm
-
Standard:
-
UL, IEC
-
Voltage Rating:
-
300V/250V
-
Current Rating:
-
20A-20A
-
Wire range:
-
26-12AWG/0.5-2.5m㎡
-
Withstanding Voltage:
-
AC2000V/Min
-
Ambient temperature:
-
-40 centigrade~+105 centigrade
-
Pin header:
-
Brass, Tin Plated
-
Housing:
-
PA66.UL94V-0
