Quick Details
-
Name:
-
Temporary outdoor event marquee tent event tent with glass walls
-
Application:
-
trade show; business conference; event; exhibition; lounge
-
Main frame:
-
hard pressed extruded aluminum alloy
-
Steel parts:
-
hot-dipped galvanized steel
-
Roof cover:
-
850g/sqm double coated pvc
-
Wall cover:
-
glass walls
-
Fixing Solution:
-
steel anchors, expand screw, weight plate
-
Allowed temperature:
-
-20° to 70° environment
-
Max wind loading capacity:
-
100km/hour
-
Snow loading:
-
25kg/sqm
Quick Details
-
Brand Name:
-
ZD tent
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
Event tent
-
Name:
-
Temporary outdoor event marquee tent event tent with glass walls
-
Application:
-
trade show; business conference; event; exhibition; lounge
-
Main frame:
-
hard pressed extruded aluminum alloy
-
Steel parts:
-
hot-dipped galvanized steel
-
Roof cover:
-
850g/sqm double coated pvc
-
Wall cover:
-
glass walls
-
Fixing Solution:
-
steel anchors, expand screw, weight plate
-
Allowed temperature:
-
-20° to 70° environment
-
Max wind loading capacity:
-
100km/hour
-
Snow loading:
-
25kg/sqm
Temporary outdoor event marquee tent event tent with glass walls
——————Size Specification——————
| Type | Span width(m) | Bay spacing(m) | Eave height(m) | Ridge height(m) | Main frame profile (mm) |
| Z&D-6 | 6 | 3 | 2.5 | 3.5 | 48X84X3 |
| Z&D-8 | 8 | 3 | 2.5 | 3.9 | 48X84X3 |
| Z&D-10 | 10 | 3 | 2.5 | 4.3 | 48X84X3/48X100X3 |
| Z&D-12 | 12 | 5 | 3 | 5.1 | 68X122X3 |
| Z&D-15 | 15 | 5 | 3 | 5.4 | 108X150X3 |
| Z&D-18 | 18 | 5 | 4 | 6.9 | 112X203X4 |
| Z&D-20 | 20 | 5 | 4 | 7.2 | 112X203X4 |
| Z&D-25 | 25 | 5 | 4 | 8.0 | 112X203X4 |
| Z&D-30 | 30 | 5 | 4 | 8.8 | 113X259X5 |
| Z&D-40 | 40 | 5 | 4 | 10.4 | 120X300X5 |
| Z&D-50 | 50 | 5 | 5 | 13 | 128X350X5 |
Width: from 3 meters to 50 meters
Length: Unlimited, extended by 3m or 5m each bay
Eave height: standard from 2.5m, 3m, 4m, to 5m upon span width(or special height per requested)
Temporary outdoor event marquee tent event tent with glass walls
Temporary outdoor event marquee tent event tent with glass walls
Temporary outdoor event marquee tent event tent with glass walls
——————Specifications——————
| Aluminum profile |
high pressed extruded aluminum alloy 6061-T6, stainless, lightweight, durable, 48X84X3mm for 3-10m tent 68x122x3mm, 88x166x3mm, 108x150x3mm, 102x203x4mm for 10-20m tent 113x259x4mm, 120x300x5mm for 20-40m tent 120x350x6mm for 40-50m tent |
| Steel parts |
hot-dipped galvanized steel |
| Top roof fabric |
850g/sqm double coated pvc, block-out, waterproof , f lame retardant meet M2 , B1, DIN4102 standard |
| Side panels(optional) |
(1) 650g/sqm double coated pvc, translucent, waterproof , f lame retardant meet M2 , B1, DIN4102 standard, or; (2)950g/sqm transparent pvc fabric, or; (3)solid walls: glass panel, sandwich panels, ABS panels, color steel sheet |
| Allowed temperature |
-20 ° to 70° environment |
| Max wind loading capacity |
10 0km/hour |
| Snow loading |
25kg/sqm |
1. 3 years guarantee, during this period we shall provide replacement freely for the parts due to quality problems.
2. Z&D tent will provide installation manual for our customers.
3.Assemble Supervisor is available from Z&D Tent to your country.
