Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VERIBEST
-
Model Number:
-
IEC 60227 H05VV-F
-
Color:
-
Black
-
Product name:
-
Multicore sheathed flexible household cable
-
100meters:
-
100meters
-
Conductor:
-
Copper Core
-
Insulation:
-
PVC Insulation Cable
-
Material:
-
PVC Copper
-
Certification:
-
CCC CE
-
Rated Voltage:
-
300/500V
-
Standard:
-
IEC 60227
-
Jacket:
-
PVC Jacket
Quick Details
-
Application:
-
Underground
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Other
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VERIBEST
-
Model Number:
-
IEC 60227 H05VV-F
-
Color:
-
Black
-
Product name:
-
Multicore sheathed flexible household cable
-
100meters:
-
100meters
-
Conductor:
-
Copper Core
-
Insulation:
-
PVC Insulation Cable
-
Material:
-
PVC Copper
-
Certification:
-
CCC CE
-
Rated Voltage:
-
300/500V
-
Standard:
-
IEC 60227
-
Jacket:
-
PVC Jacket
Product Description
APPlication
1, RVV implementation of the standard GB/T5023.5-2008
2, the rated voltage is 602271EC52 (300/300V) 2271EC53 (300/500V)
3. PVC sheath
4, PVC insulation
5, conductor multiple core return naked copper stranded
6. Normal working temperature shall not exceed 70℃
7. The product has passed CCC certification
Suitable for control signal transmission line, electrical equipment, instrumentation, automation equipment, security and anti-theft alarm system, high-rise building intercom system, household lighting connection line, etc
Product parameter information
|
Product name
|
Product model
|
Rated voltage
|
Specifications
|
Number cores
|
|
General purpose single core hard conductor sheathless cable
|
60227 IEC 01 (BV）
|
450/750V
|
1.5~50
|
Single core
|
|
General purpose single core flexible conductor sheathless cable
|
60227 IEC 02（RV）
|
450/750V
|
1.5~50
|
Single core
|
|
Single core flexible conductor sheathless cable
|
60227 IEC 06（RV）
|
300/500V
|
0.5~1.0
|
Single core
|
|
Copper core PVC insulated flexible cable
|
BVR
|
450/750V
|
1.0~50
|
Single core
|
|
Copper core PVC insulated PVC sheathed shielded flexible wire
|
RVVP
|
300/300V
|
0.3~6.0
|
2-16 cores
|
|
Copper core PVC insulated stranded flexible wire for connection
|
RVS
|
300/300V
|
0.75~4
|
2 cores
|
|
Copper core PVC insulated PVC sheathed flexible cable
|
RVV
|
300/500V
|
4-6
|
2-5 cores
|
|
|
|
|
0.3-2.5
|
6-16cores
|
|
Ordinary PVC sheathed wire
|
60227 IEC 53（RVV）
|
300/500V
|
0.75-2.5
|
2-5cores，round
|
|
color
|
white,black,grey or OEM
|
|
Conductor
|
Flexible Copper
|
|
Normal Sections
|
0.5mm²，0.75mm² ，1.0mm²，1.5mm²，2.5mm²，4.0mm²，6.0mm²。
|
|
Material
|
PVC and Copper
|
|
Certification
|
CCC,CE, ISO9001
|
|
Rated Voltage
|
300/300V 300/500V
|
|
Standard
|
IEC60227;GB/T5023;BS6500;VDE0281;JB/T8734
|
|
Keyword
|
RVV flexible electric cable
|
|
Core
|
2-40Core
|
|
Type
|
insulated
|
|
Application
|
Heating
|
|
Conductor Material
|
Copper/cca
|
|
Conductor Type
|
Stranded
|
|
Insulation Material
|
PVC
|
|
Place of Origin
|
Guangdong,China
|
|
Model Number
|
RVV
|
specification
|
Voltage grade
(V)
|
Cross-sectional Area
(mm2)
|
Conductor combination
（mm）
|
Insulation thickness
（mm）
|
Toplimit of overall diameter
（mm）
|
|
300/500V
|
2x1.0
|
32/0.2
|
0.6
|
8.0
|
|
|
2x1.5
|
48/0.2
|
0.7
|
9.0
|
|
|
2x2.5
|
80/0.2
|
0.8
|
11.0
|
|
|
2x4.0
|
128/0.2
|
0.8
|
12.4
|
|
|
2x6.0
|
192/0.2
|
1.0
|
13.4
|
|
|
3x1.0
|
32/0.2
|
0.6
|
8.4
|
|
|
3x1.5
|
48/0.2
|
0.7
|
9.8
|
|
|
3x2.5
|
80/0.2
|
0.8
|
12.0
|
|
|
3x4.0
|
128/0.2
|
0.8
|
13.5
|
|
|
3x6.0
|
192/0.2
|
1.0
|
14.5
|
|
|
4x1.0
|
32/0.2
|
0.6
|
9.4
|
|
|
4x1.5
|
48/0.2
|
0.7
|
11.0
|
|
|
4x2.5
|
80/0.2
|
0.8
|
13.0
|
|
|
4x4.0
|
128/0.2
|
0.8
|
14.6
|
|
|
4x6.0
|
192/0.2
|
1.0
|
16.0
|
|
|
5x1.0
|
32/0.2
|
0.6
|
10.0
|
|
|
5x1.5
|
48/0.2
|
0.7
|
12.0
|
|
|
5x2.5
|
80/0.2
|
0.8
|
14.0
|
|
|
5x4.0
|
128/0.2
|
0.8
|
16.5
|
|
|
5x6.0
|
192/0.2
|
1.0
|
18.5
|
