Quick Details
-
Brand Name:
-
YRO
-
Model Number:
-
YRQ2CB-63
-
Rated Current:
-
63A
-
Product name:
-
Automatic Transfer Switch
-
Pole:
-
2P
-
Rated voltage:
-
AC230A
-
Current:
-
63A
-
Frequency:
-
60Hz
-
Uimp:
-
4KV
-
Certificate:
-
CE
Quick Details
-
Type:
-
CB
-
Number of Pole:
-
2
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YRO
-
Model Number:
-
YRQ2CB-63
-
Rated Current:
-
63A
-
Product name:
-
Automatic Transfer Switch
-
Pole:
-
2P
-
Rated voltage:
-
AC230A
-
Current:
-
63A
-
Frequency:
-
60Hz
-
Uimp:
-
4KV
-
Certificate:
-
CE
Specification
|
Type
|
YRQ2CB-63
|
|
|
|
|
Specification current Ie(A)
|
6/10/16/20/25/32/40/50/63
|
|
|
|
|
Rated operating voltage, Ue (V)
|
AC230V/AC400V
|
|
|
|
|
Rated insulating voltage Ui (V)
|
AC 690V
|
|
|
|
|
Rated impulse withstand voltage (KV)
|
4KV
|
|
|
|
|
Rated short circuit making capacity Icm
|
6KA
|
|
|
|
|
Rated short circuit breaking capacity Icn
|
4.5KA
|
|
|
|
|
Service life
|
5000 times
|
|
|
|
|
Electric equipment grade
|
CB Class
|
|
|
|
|
Controller
|
Type A(basic type)
|
|
|
|
|
Rated control supply voltage,Us(V)
|
230V 50/60Hz
|
|
|
|
|
Operating transfer time (no time delay)
|
≤3s
|
|
|
|
|
