Quick Details
-
Type::
-
Washing and filling machine
-
material::
-
SUS 304
-
Model Number:
-
single head or 2 head
Quick Details
-
Place of Origin:
-
Shandong, China
-
Control::
-
Siemens PLC
-
Automatic Grade::
-
Automatic
-
Type::
-
Washing and filling machine
-
material::
-
SUS 304
-
Model Number:
-
single head or 2 head
Beer keg washing filling unit machine
1, Specification
|
table-board size |
1200mm×450mm |
|
table-board height |
700mm |
|
exterior dimension |
1200mm×1400mm×1900mm |
|
cylinder max stroke |
300mm |
|
net weight |
260Kg |
|
power |
18KW |
|
Heating |
(electrical heating) 220V three-phase |
|
capacity |
20~40kegs/hour |
|
cleaning mode |
keg topside down |
|
applicable keg |
diameter φ250~φ500, height 360mm~600mm |
2, Technical parameter
|
air source pressure |
0.6 ~ 0. 7 Mpa |
|
CO 2 source pressure |
0. 3~ 0. 4 Mpa |
|
c ylinder valve pressure |
0. 5~ 0. 6 Mpa |
|
CO 2 valve pressure |
0. 2~ 0. 3 Mpa |
|
A ir-blow valve pressure |
0.2Mpa |
|
s terile water pressure |
0. 4 Mpa |
|
p ower voltage |
T hree-phase 220V 6 0Hz |
3 . Main Structures and Feature s
This machine mainly contains the frame, electric system, air system and other pipeline system. The features are as below :
1. All parameters (t ime values ) can be adjusted without stopping the machine.
2. Maximum straight-line design on main cleaning pipelines makes sure the powerful and thorough scouring.
3. Twin -acting pneumatic valve with reliable quality and anti-high temperature characteristic .
4. Adoption of world top product s as main accessories makes sure premium quality.
5. The sterile water and th e lye water can be recyclable.
4. Working Procedures
Load the keg → start (cylinder pressing tightly) → air blowing (drain ing residue) → scoured by clean water → air blowing (drain ing water) → scoured by lye water → extracting tube scoured by lye water → air blowing and recycle → scour ed by clean water → extracting tube scoured by clean water → air blowing (drain ing water) → scour ed by clean water → air blowing → scoured by sterile water → air blowing → prepare CO 2 pressure → reset the cylinder → unload the keg
beer kegs Filling machine
5. Usual Malfunction and Removing Method
|
Malfunction |
Possible reason |
Moving method |
|
Leakage of cleaning head |
loose cylinder |
check the cylinder pressure |
|
incorrect orientation |
orient the keg correctly |
|
|
loose gasket |
Adjust gasket |
|
|
Power disconnection of PLC |
incorrect voltage value |
check the power |
|
high ampere value(≥3A) |
check the circuit |
|
|
Extinguishing of indicator |
Indicator damage |
change the indicator |
|
Remaining liquid in keg after cleaning process |
insufficient air-blowing time |
adjust air-pumping time |
|
damaged extracting tube |
change extracting tube |
|
|
Virus standard unconformity |
expired disinfectant |
change disinfectant |
