Quick Details
-
Filling Accuracy:
-
2mm
-
Voltage:
-
110V/220/,50HZ/60HZ, 220V/380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinri
-
Dimension(L*W*H):
-
1800*1600*2250
-
Weight:
-
2000 KG
-
Product name:
-
Beer Filling Machine
-
capacity:
-
1000BPH
-
material:
-
SUS304
-
bottle type:
-
glass bottle
-
bottle volume:
-
330ml,500ml
-
After-sales Service Provided:
-
Video Technical Support
-
Processing Types:
-
rinsing filling and capping
-
filling method:
-
isobaric
-
vacumm:
-
once or twice
Quick Details
-
Machinery Capacity:
-
1000BPH
-
Packaging Material:
-
Plastic, Metal, Glass
-
Filling Material:
-
Beer
-
Filling Accuracy:
-
2mm
-
Voltage:
-
110V/220/,50HZ/60HZ, 220V/380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinri
-
Dimension(L*W*H):
-
1800*1600*2250
-
Weight:
-
2000 KG
-
Product name:
-
Beer Filling Machine
-
capacity:
-
1000BPH
-
material:
-
SUS304
-
bottle type:
-
glass bottle
-
bottle volume:
-
330ml,500ml
-
After-sales Service Provided:
-
Video Technical Support
-
Processing Types:
-
rinsing filling and capping
-
filling method:
-
isobaric
-
vacumm:
-
once or twice
Products Description
Zhangjiagang Jinri Packaging Machinery Co., Ltd.
Zhangjiagang Jinri Packaging Machinery Co., Ltd. is a professional manufacturer of beverage machinery in China.Our main products have: Water filling production line, juice filling production line, carbonated drinks filling production line, and also aerosol filling machine, 5 Gallon bottle filling production line, and all other auxiliary equipment. Our engineers are located all over the world and can provide safe and fast service to your beverage production solutions in your country.
Details Images
Beer Filling Machine
Automatic glass bottle Soft drinks rinser filler capper 3-in-1 filling Triblock, combined with rinsing, filling and capping. It is
innovated and designed in the requirement of carbonated soft drinks, beer, energy drink, and soda water, on the basis of
introducing, digesting and absorbing advanced technology from Germany.
The machine is a full-automatic multiple-function washing, filling and capping unit. It is used in washing. filling and sealing
all kinds of carbonated drinks such as beer, soft drink, energy drink mineral water and pure water. The line has features of
unique design,new style, complete functions,multi-purpose, convenient in operation, compact construction, high automaticity. It is the best filling equipment in China.
innovated and designed in the requirement of carbonated soft drinks, beer, energy drink, and soda water, on the basis of
introducing, digesting and absorbing advanced technology from Germany.
The machine is a full-automatic multiple-function washing, filling and capping unit. It is used in washing. filling and sealing
all kinds of carbonated drinks such as beer, soft drink, energy drink mineral water and pure water. The line has features of
unique design,new style, complete functions,multi-purpose, convenient in operation, compact construction, high automaticity. It is the best filling equipment in China.
Washing Part
rotary washing machine, used for beverage such as beer or carbonated drink, new bottle enter the equipment by starwheel, through gripper and overturn mechanism make bottle down, after washing, it overturn bottle up automatically, then convey tothe filling part by star steel, the main material and washing gripper is stainless steel .
Filling Part
Filling valve use isobar machinery valve, double vacuum valve, or flow meter counter pressure filler valve, with High speed andbig flow, the high accuracy filling valve, filling speed fast, the liquid level is stable.
Main drive adopt gear drive independent, high efficiency, small noise, long life, maintenance-free, transducer can control themain motor speed, the machine adopt Variable-frequency variable speed, whole operations area.
Main drive adopt gear drive independent, high efficiency, small noise, long life, maintenance-free, transducer can control themain motor speed, the machine adopt Variable-frequency variable speed, whole operations area.
Capping- Part
Stainless steel capping plunger and mechanical stirring magnetic cap sorter ensure hygienic and reliable capping. The hopper,captaking and capping are all transferred by magnets, the capping is reliable, and it has an automatic unloading function to reduce the rate of broken bottles.
|
Model
|
Rinsing
heads
|
Filling
heads
|
Capping
heads
|
Capaclty
(BPH)
|
Motor
power(KW)
|
Dimension(mm)
|
Weight(kg)
|
|
BCGF8-6-1
|
8
|
6
|
1
|
500
|
1.1
|
1800*1280*2550
|
1200
|
|
BCGF14-12-4
|
14
|
12
|
4
|
1200
|
4.3
|
2000*1740*2750
|
2300
|
|
BCGF18-18-6
|
18
|
18
|
6
|
1800
|
4.5
|
2370*1890*2750
|
3500
|
|
BCGF24-24-8
|
24
|
24
|
8
|
3000
|
6
|
2760*2800*2850
|
5100
|
|
BCGF32-32-10
|
32
|
32
|
10
|
6000
|
9
|
4060*2285*2850
|
7300
|
|
BCGF40-40-12
|
40
|
40
|
12
|
10000
|
11
|
4020*3110*2850
|
9600
|
|
BCGF50-50-15
|
50
|
50
|
15
|
13000
|
15
|
5460*3300*2950
|
12500
|
|
BCGF60-60-15
|
60
|
60
|
15
|
15000
|
21
|
5556*4239*2950
|
16200
|
|
BCGF72-72-1
|
72
|
72
|
18
|
20000
|
24
|
6375*4820*3050
|
19700
|
