Quick Details
-
Place of Origin:
-
Hubei, China
-
Displacement:
-
500cc
-
Model Name:
-
LNA-U500
-
Dimensions:
-
3035*1685*2400mm
-
Drive:
-
Switchable 2WD/4WD
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Top speed:
-
80-90 km/h
-
Weight:
-
500kg
-
Max Weight load:
-
200-300 kg
-
Colors:
-
Customized
Quick Details
-
Brand Name:
-
LNA
-
Tire Size:
-
25*8-12/25*10-12
-
Dimension:
-
3035*1685*2400mm
-
Place of Origin:
-
Hubei, China
-
Displacement:
-
500cc
-
Model Name:
-
LNA-U500
-
Dimensions:
-
3035*1685*2400mm
-
Drive:
-
Switchable 2WD/4WD
-
Clutch:
-
Automatic
-
Brake:
-
Hydraulic Disc Brake
-
Top speed:
-
80-90 km/h
-
Weight:
-
500kg
-
Max Weight load:
-
200-300 kg
-
Colors:
-
Customized
Product Description
Specification
|
Model Number
|
LNA-U500
|
Type
|
Switchable 2WD/4WD
|
|
Size
|
3035*1685*2400mm
|
Top speed
|
80-90 km/h
|
|
Clutch
|
Automatic
|
Start
|
Electric
|
|
Wheelbase
|
2400mm
|
Cooling
|
Water cooled
|
|
Weight
|
500 kg
|
Max weight load
|
300-400 kg
|
|
Front track
|
278
|
Rear track
|
177
|
|
Battery
|
12v,18AH
|
Fuel Tank
|
20L
|
|
Brake
|
Hydraulic Disc Brake
|
Front wheel
|
25*8-12
|
|
Rear wheel
|
25*10-12
|
Ground clearance
|
320mm
|
|
Color
|
Black,Green,Red etc
|
Packing size
|
5CBM
|
|
Engine model
|
4 stroke
|
Compression ratio
|
10:1
|
|
Idel speed
|
1300/rpm
|
Carburetor
|
CV Type
|
|
Braking distance
|
Less 7m/30km/h
|
Transmission
|
Shaft
|
Detailed Pictures
The Driving Seat
The roomy rider-seat provides spacious space for the riders even you are tall and strong ,the knees and legs will be comfortable when ride.
LED Speedmeter and Switchable 2WD/4WD
The smart LED speedmeter shows speed,miles,all the info can be easily seeing
Switchable 2WD and 4WD supported
Seaters
5-points style sporty seatbelts included,just not shown in this picture
Hand Brake and Gear lever
4x4 Transfer box in front
Real 4x4 provides powerful off road capacity
Shaft drive with
Hydraulic Disc Brake
Rear side
Shaft Drive 4x4 in Rear
Independent suspensions in rear and Tow bar supported
Hydraulic Disc Brake in Rear
Top Luggage Rack Supported
Certifications
Product packaging
The packing is made by steel frame with carbon box and covered by plastic. strong enough for the transport.
