Quick Details
-
Controller Type:
-
MPPT, NONE
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE/IEC62109, G83/G59, VDE0126-1-1,AS4777, CE/IEC62109, G83/G59, VDE0126-1-1,AS4777
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Greensun
-
Model Number:
-
GS-8000-HY
-
Output Voltage (V):
-
110V -380V
-
Output Frequency:
-
50/60hz
-
Work Time (h):
-
24 Hours
-
Specification:
-
8KW Hybrid Solar System
-
Product name:
-
Solar system
-
Solar panel:
-
Mono/Poly 10BB/12BB/16BB
-
Inverter type:
-
Grid Hybrid Solar Inverter
-
Montiring:
-
Wifi/GPRS
-
Battery:
-
Lead Acid/Lithium Battery
-
Mounting structure:
-
Roof Ground Type
-
OEM Service:
-
Acceptable
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion, NONE
-
Controller Type:
-
MPPT, NONE
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE/IEC62109, G83/G59, VDE0126-1-1,AS4777, CE/IEC62109, G83/G59, VDE0126-1-1,AS4777
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Greensun
-
Model Number:
-
GS-8000-HY
-
Output Voltage (V):
-
110V -380V
-
Output Frequency:
-
50/60hz
-
Work Time (h):
-
24 Hours
-
Specification:
-
8KW Hybrid Solar System
-
Product name:
-
Solar system
-
Solar panel:
-
Mono/Poly 10BB/12BB/16BB
-
Inverter type:
-
Grid Hybrid Solar Inverter
-
Montiring:
-
Wifi/GPRS
-
Battery:
-
Lead Acid/Lithium Battery
-
Mounting structure:
-
Roof Ground Type
-
OEM Service:
-
Acceptable
Product Description
|
Model
|
SPI-8K-U
|
SPI-10K-U
|
||
|
INVERTER
|
|
|
||
|
Rated Output Power
|
8000W
|
10000W
|
||
|
Max.Peak Power
|
16000W
|
20000W
|
||
|
Rated Output Voltage
|
120/240Vac（L1/L2/N/PE split phase）
|
|
||
|
Rated AC Frequency
|
50/60Hz
|
|
||
|
Waveform
|
Pure Sine Wave
|
|
||
|
Switch Time
|
10ms（typical）
|
|
||
|
BATTERY
|
|
|
||
|
Battery Type
|
Li-ion / Lead-Acid / User Defined
|
|
||
|
Rated Battery Voltage
|
48Vdc
|
|
||
|
Voltage Range
|
40～60Vdc
|
|
||
|
Max.MPPT Charging Current
|
100A
|
|
||
|
Max.Mains/Generator Charging
|
100A
|
120A
|
||
|
Max.Hybrid Charging Current
|
180A
|
200A
|
||
|
COMMUNICATION
|
RS485/CAN/USB/ Dry contact
|
|
||
|
PV INPUT
|
|
|
||
|
Num. of MPPT Trackers
|
2
|
|
||
|
Max.PV Array Power
|
11000W
|
|
||
|
Max.Input Current
|
22/22A
|
|
||
|
Max.Voltage of Open Circuit
|
500Vdc
|
|
||
|
MPPT Voltage Range
|
125~425Vdc
|
|
||
|
GENERAL
|
|
|
||
|
Dimensions
|
620*435*130mm
|
|
||
|
Weight
|
20kg （44lb)
|
21kg （46.3lb）
|
||
|
Protection Degree
|
IP20，Indoor Only
|
|
||
|
Operating Temperature Range
|
-10~55℃,>45℃ derated
|
|
||
|
Humidity
|
-25°C ~ 60°C
|
|
||
|
Cooling Method
|
Internal Fan
|
|
||
|
External Modules（Optional）
|
Wi-Fi / GPRS
|
|
||
