Main Features:

• Heavy duty cast iron pump
• Premium quality
• Powder coat painting enhances antirust
• Greater realiability
• Efficient cooling system
• Long term durability
• Regulation: Auto Stop/Start, 2340 thru 2545. Constant speed 7100 thru 3000 series
• Receiver ASME - 220 PSIG (15.2 kg/cm2) max. Operation temperature 250°C
• Tank mounted model, starter mounted on machine
• Baseplate mounted model, DOL starter mounted on machine, SDS starter shipping loose with machine

What do you get from a Standard Package

• Direct-on-line starter on standard package power below 15HP (includes 15HP)
• Totally enclosed wired beltguard
• Oil level sight glass
• Interstage safety valve & pressure gauge
• Discharge check valve & safety valve
• Manual drain valves on interstage drain legs
• Efficient TEFC electric motor, IP54, 1.15 S.F
• Rugged steel baseplate
• Factory filled XL740HT synthetic lubricant

Horizontal Tank Mounted

Model	Power (kW)	Capacity		Operating bar(g)	Pressure psi(g)	Motor	Dimensions (mm) LxWxH	Weight (kg)	Air Tank (litre)
		m3/min	f3/min
2340K3/12	2.2	0.27	9.6	12.3	175	220-230v/ 1ph/50hz	1,440x 540x970	223	150
2340K5/12	4.1	0.38	13.2	12.3	175	380-415v/ 3ph/50hz	1,440x 540x970	240	150
2340L5/12	2.2	0.27	9.6	12.3	175	380-415V/ 3ph/50hz	860x 540x1,850	223	227

• Reciprocating
• Rotary Screw
• Centrifugal
• Oil Free Rotary Screw
• Dryers
• Filters
• Controls
• PET Blow Molding

2340K3/12 2475K5/12 2475K7/12 2545C7/12 2545C10/12 7100D15/12 7100D15/12 3000E20/12 3000E25/12 3000E30/12

Reciprocating Air Compressors

Ingersoll Rand has maintained a delicate balance between known performance and new technology developments to manufacture world class reciprocating air compressors. With a proven design and stellar track record, the Ingersoll Rand reciprocating compressor family has earned worldwide recognition for reliable, trustworthy performance that saves money and enhances business success through: Lower life cycle costs; An ability to thrive in punishing applications; Configurations that meet varying needs; Optimum solutions for greater efficiency; Our cumulative experience with how different users prefer, need and operate their compressors has taught us what is most important to compressor users.

• Non-Lubricated
• Single-Stage
• Two-Stage
• High-Pressure
• Oil-Lubricated
• Vacuum Pumps

Electric-Driven Two-Stage Air Compressors

T30 Two Stage Reciprocating Compressor

The Ingersoll-Rand T30 has been the leader in its class since it was introduced in 1929. Whether this is measured by reliability, efficiency, rugged flexibility or maintainability, it has no equal.
Designed for heavy industrial applications, the two stage reciprocating air compressors provide the quality and performance that exceed customer requirements.
Others may claim to handle heavy duty applications, but the T30 defines the concept. Run it in the most demanding intermediate duty application imaginable.
It won’t make any difference because this compressor performs with total dependability in the most demanding, heavy-duty industrial applications.
Throughout this brochure we try to show you some of the features which make the T30 unique and ideal to meet your demands of a compressor package in the 2-30 HP range.
Many compressor applications need care and experience to ensure that the correct machine and configuration is selected to provide the level of efficiency and reliability which you expect.
Our Sales offices and Distributors are ideally qualified and experienced to assist you in this task. If you are seeking information about a new compressor, advice about an existing installation or ancillary equipment or spare parts, you will find knowledge available to assist you.

Designed for heavy shop or industrial use, Ingersoll Rand Electric-driven Two-stage air compressors provide the reliability and performance that are ideal for most applications and users including automotive service and body shops, fleet maintenance, machine shops, production and manufacturing lines, wood working shops, dry cleaners, car washes, general maintenance/repair shops and farms.

FEATURES :

• Durable cast iron design for 100% continuous duty application

• Precision engineered components for high reliability

• Individually cast cylinders, overhung crankshaft and one piece connecting rod for ease of maintenance and service

• High efficiency finger valves

• 175 psig maximum operating pressure for applications requiring high air capacity and pressure

• Extended 2 year warranty when used with Ingersoll Rand’s All Season Select synthetic lubricant

• Choice of Value, Value Plus and Premium packages to suit diversified customer needs

Standard Features
• CE Marked receivers to 87/404/EEC
• 4 pole IP55 TEFV Motor
• Standard voltage 400-3-50
• Auto Start and Stop regulation by pressure switch up to 7.5 hp
• Dual control regulation on 10hp to 30hp receiver mounted units
• Constant Speed Control on 10hp to 30hp Base Mounted units
• DOL starting by pressure switch up to 7.5hp
• DOL starter (10hp to 30hp)
• Star Delta Starter available from 5.5hp
• Low oil level switch fitted from 10hp to 30hp
• Totally enclosed belt guard design
• Dry type inlet filter
• Flexible discharge tube
• Factory-fill of lubricant
