Quick Details
-
Brand Name:
-
GrandPaw
-
Model Number:
-
192119
-
Warranty:
-
12 Months
-
Reader Unit:
-
Bayonet Style Gauge
-
Chuck Type:
-
Dual Head Air Chuck
-
Max. Inflation:
-
120 PSI
-
Scale:
-
PSI
-
Inlet Size:
-
1/4" NPT / BSP female
-
Hose Length:
-
15.7"(400mm)
-
Housing:
-
Zinc Alloy Die Casting
-
Trigger:
-
Plated Steel
-
Max. Airline Pressure:
-
170 PSI
-
Operation:
-
Inflate, Measure
Quick Details
-
Car Fitment:
-
KAMA, Ram Van, NAZA, e-one, Opel, E.GO
-
Size:
-
274*104*38mm
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
GrandPaw
-
Model Number:
-
192119
-
Warranty:
-
12 Months
-
Reader Unit:
-
Bayonet Style Gauge
-
Chuck Type:
-
Dual Head Air Chuck
-
Max. Inflation:
-
120 PSI
-
Scale:
-
PSI
-
Inlet Size:
-
1/4" NPT / BSP female
-
Hose Length:
-
15.7"(400mm)
-
Housing:
-
Zinc Alloy Die Casting
-
Trigger:
-
Plated Steel
-
Max. Airline Pressure:
-
170 PSI
-
Operation:
-
Inflate, Measure
Product Paramenters
|
Part Number
|
192119
|
|
Reader Unit
|
Bayonet Style Gauge
|
|
Chuck Type
|
Dual Head Air Chuck
|
|
Max. Inflation
|
120 PSI
|
|
Scale
|
PSI
|
|
Inlet Size
|
1/4" NPT / BSP female
|
|
Hose Length
|
15.7"(400mm)
|
|
Housing
|
Zinc Alloy Die Casting
|
|
Trigger
|
Plated Steel
|
|
Accuracy
|
+/- 2%
|
|
Operation
|
Inflate, Measure
|
|
Max. Airline Pressure
|
170 PSI
|
|
Deflation Valve
|
(optional)
|
192119 Bayonet Inflator Gauge
•Heavy duty bayonet style inflator gauge with brass valve mechanism will provide years of reliable service
•Protective sleeve over dial tube for impact protection, withstands the tough home garage or commercial shop use.
•Solid brass bar gauge calibrated 10 – 120 PSI in 2 PSI increments
•Heavy duty cast body construction is designed for longevity and durability
•Dual head chuck makes tire valve more accessible.
•Max 300 PSI hybrid rubber hose, 1/4” NPT or BSP air inlet
How do I know if my tires are properly inflated?
Even if your car is equipped with TPMS, you will want to know the recommended tire pressure for your specific vehicle. Typically, there is a sticker found inside the driver’s side door that will list the recommended tire pressure. This figure is normally indicated in PSI, which stands for pounds per square inch of air. In addition, your tire’s maximum air pressure will be labeled on the tire’s sidewall. That figure is the maximum PSI the tire can safely hold. In other words, don’t inflate your tires beyond the number found on the sidewall.
If you are not able to locate a sticker on the inside of your driver’s side door, refer to the owner’s manual to determine the recommended tire pressure for your car.
Keep in mind that the recommended tire pressure values could be different between your front and rear tires. Make sure you’re checking both front and rear values when you’re determining whether your tires are properly inflated.
Main Products
About Us
Our Advantages
Certifications
Exhibition
Packaging & Shipping
FAQ
Q1. Why Choose Us?
We are a more than 10 years professional manufacturer in tire gauges, tire inflators and automotive tools with high quality and competitive price. We mainly focus on professional level, most of our end customers are workshops, car repair centers, tire shops etc.
Q2. What's your items guarantee?
Some of our items we provide 12 months warrantee.
Q3. How long is the lead time?
For inventory goods, we will delivery within 5 working days. For customized orders, our lead time is 30-60 days.
Q4.What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. What is your terms of delivery
A: EXW, FOB, CFR, CIF
