Quick Details
-
Brand Name:
-
OEM&ODM
-
Model Number:
-
GCN8H44H
-
Dimension (L x W x H):
-
D208xH120mm
-
Musical power(W):
-
600LF-80HF
-
Nominal power AES (W):
-
300LF- 40HF
-
Nominal diameter(''/mm):
-
8'' (210mm)
-
Nominal Impedance(ohm):
-
8LF-8HF
-
Voice coil diameter(mm):
-
65mm LF- 40mm HF
-
Sensitivity 1W/1m(dB):
-
93.5dB LF-98dB HF
-
Frequency Range:
-
76Hz-20KHz
-
Overall diameter:
-
208mm
-
Total depth:
-
120mm
-
Keywords:
-
8'' coaxial speaker
Quick Details
-
Power:
-
700Watts
-
Frequency Range (Hz):
-
76Hz-20KHz
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
OEM&ODM
-
Model Number:
-
GCN8H44H
-
Dimension (L x W x H):
-
D208xH120mm
-
Musical power(W):
-
600LF-80HF
-
Nominal power AES (W):
-
300LF- 40HF
-
Nominal diameter(''/mm):
-
8'' (210mm)
-
Nominal Impedance(ohm):
-
8LF-8HF
-
Voice coil diameter(mm):
-
65mm LF- 40mm HF
-
Sensitivity 1W/1m(dB):
-
93.5dB LF-98dB HF
-
Frequency Range:
-
76Hz-20KHz
-
Overall diameter:
-
208mm
-
Total depth:
-
120mm
-
Keywords:
-
8'' coaxial speaker
| Model Number | GCN8H44H |
| Musical power(W) | 600LF-80HF |
| Nominal power AES (W) | 300LF- 40HF |
| Nominal diameter(''/mm) | 8'' (210mm) |
| Nominal Impedance(ohm) | 8LF-8HF |
| Voice coil diameter(mm) | 65mm LF- 40mm HF |
| Sensitivity 1W/1m(dB) | 93.5dB LF-98dB HF |
| Frequency Range | 76Hz-20KHz |
| Re | 6.8ohm LF-6ohm HF |
| Fs | 76Hz |
| Qms | 5.11 |
| Qes | 0.41 |
|
Qts |
0.38 |
| Mms | 102.82g |
| Cms | 0.04mm/N |
| Sd | 200cm2 |
| Vas | 2.73L |
| BL | 28.38Tm |
| Xmax | +/-6mm |
| Le(1kHz) | 0.70mH |
| Basket Type | Aluminium Die-Cast |
| Magnet Type | Neodymium |
| Cone Material | Paper |
| Suspension Material | Treated Cloth |
| Spider Material | Fabric |
| Former Material | Fiberglass LF-Kapton HF |
| Winding Material | Copper LF |
| Connector Type | Faston |
| Cone Shape | Exponential |
