Quick Details
-
Brand Name:
-
Alion
-
Model Number:
-
SYN161d
-
Item:
-
Analogue Time Switch SYN161d
-
Operating Voltage:
-
AC230V
-
Frequency:
-
50-60 Hz
-
Program:
-
Daily program
-
Shortest Switching Time:
-
15 min
-
Width:
-
3 modules
-
Installation type:
-
DIN-rail
-
Number of Switching Segments:
-
96 times
-
Power Reserve:
-
200 hours
-
Certificates:
-
CE ROHS
Quick Details
-
Theory:
-
Mechanical
-
Usage:
-
Timer Switch
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Alion
-
Model Number:
-
SYN161d
-
Item:
-
Analogue Time Switch SYN161d
-
Operating Voltage:
-
AC230V
-
Frequency:
-
50-60 Hz
-
Program:
-
Daily program
-
Shortest Switching Time:
-
15 min
-
Width:
-
3 modules
-
Installation type:
-
DIN-rail
-
Number of Switching Segments:
-
96 times
-
Power Reserve:
-
200 hours
-
Certificates:
-
CE ROHS
SUL181d 230VAC programmable din rail analogue delay timer switch
Focus On Time Control For 24 Years
The SUL181d/SYN161d daily program analog time switches are programmed using switching segments, it's quickly read and easy to change. The shortest switching time is 15 minutes and it can switching with continuous ON/AUTO/continuous OFF.
Description
- Analogue time switch
- 1 channel
- Daily program
- 96 switching segments
- Quartz controlled
- Shortest switching time: 15 minutes
- Clock hands for time display and in addition 12/24 hour recognition
- Simple summer/winter time correction
- Time can be changed clockwise
- DuoFix spring terminals
- For 2 conductors each
- Wire or strand (with or without wire end sleeve)
- Wire diameter: 0.5 - 2.5 mm²
- Button for releasing plug-in connection
- Switching preselection
- Manual switch with 3 positions:Permanent ON/AUTO/permanent OFF
- Switching status display
SUL181d
- With power reserve (NiMH rechargeable battery)
SYN161d
- Without power reserve
Applications
- Billboard or Showcase lighting
- Air-condition or Commercial Refrigeration
- Pumps/Motor/Geyser/Fan Control
- Hydroponic Systems
- Wastewater Treatment Systems
- Generator Exercising
- Boilers / Heater Control
- Pool & Spa
Technical data
| Type | SUL181d | SYN161d |
| Operating voltage | 230-240 VAC / 110VAC / 24VDC / 12VDC | |
| Frequency | 50-60Hz | |
| Number of channels | 1 | |
| Width | 3 modules | |
| Installation type | DIN-rail | |
| Type of connection | Screw terminals | |
| Drive | Quartz-controlled stepper motor | |
| Program | Daily program | |
| Power reserve | 200 hours approx. 100 hours at 110 V | Without power reserve |
| Max. switching capacity at 250 V AC, cos φ = 1 | 16 A | |
| Max. switching capacity at 250 V AC, cos φ = 0.6 | 4 A | |
| Incandescent/halogen lamp load | 1100W | |
| LED lamp < 2 W | 20W | |
| LED lamp > 2 W | 180W | |
| Shortest switching time | 15 min | |
| Programmable every | 15 min | |
| Number of switching segments | 96 | |
| Time accuracy at 25 °C | ≤ ± 2 s/day(Quartz) | |
| Type of contact | Changeover contact | |
| Switching output | Potential-free and phase-independent | |
| Power consumption | 1.5VA | |
| Test approvals | CE | |
| Housing and insulation material |
High-temperature resistant self-extinguishing thermoplastic |
|
| Type of protection | IP 20 | |
| Protection class | II in accordance with EN 60730-1 | |
| Ambient temperature | –10 °C … +50 °C | |
Connection Example
Scale Drawings
