Quick Details
-
Weight:
-
8500 KG
-
Brand Name:
-
ORIEMAC
-
Engine brand:
-
WEICHAI
-
weight:
-
19700.000kg
-
Engine Power.:
-
178/2200 kwrpm
-
Displacement:
-
10L
-
Steering angle:
-
389
-
Tire model:
-
23.5-25
-
Winch drive type:
-
Hydraulic motor drive
-
Maximum wirerope speed:
-
10 m/min
-
Width of winch drum:
-
230 mm
Quick Details
-
Use:
-
pull timber, pull log,winch
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
7900X3300X3500
-
Weight:
-
8500 KG
-
Brand Name:
-
ORIEMAC
-
Engine brand:
-
WEICHAI
-
weight:
-
19700.000kg
-
Engine Power.:
-
178/2200 kwrpm
-
Displacement:
-
10L
-
Steering angle:
-
389
-
Tire model:
-
23.5-25
-
Winch drive type:
-
Hydraulic motor drive
-
Maximum wirerope speed:
-
10 m/min
-
Width of winch drum:
-
230 mm
Contact way
Carlota ji
Whatsapp/Tel:
+86-18637752754
Wechat:
+86-18637752754
Email:
carlota@oriemac.com
Product features
240hp Wood skidder XC360 19ton Winch hydraulic wheel forestry log Skidder for sale
XC360 log skidder is a wheeled type skidding tractor, with four-wheel driven and hydraulic steering. The skidder possesses good flexibility, high running speed and good cross-country feature in the forest. The machine is equipped with a working device in multi-functions. So it is an ideal log skidder in wood transportation, stacking, rushing to deal with emergency, rescuing and many other additional operations.
01. Operating weight: 19700kg
02. WEICHAI 178kW (242hp) engine
03. Gear: four forward and four back
04. Tire model: 23.5-25 herringbone 05. Wheelbase: 3680 mm
XC360 log skidder is a wheeled type skidding tractor, with four-wheel driven and hydraulic steering. The skidder possesses good flexibility, high running speed and good cross-country feature in the forest. The machine is equipped with a working device in multi-functions. So it is an ideal log skidder in wood transportation, stacking, rushing to deal with emergency, rescuing and many other additional operations.
01. Operating weight: 19700kg
02. WEICHAI 178kW (242hp) engine
03. Gear: four forward and four back
04. Tire model: 23.5-25 herringbone 05. Wheelbase: 3680 mm
Specifications
|
weight
|
19700.000kg
|
|
Engine model
|
Weichai WD10G240E201
|
|
Engine Power.
|
178/2200 kwrpm
|
|
Displacement
|
10L
|
|
Gear
|
Four forward and four reverse
|
|
Speed
|
Forward I/reverse 1:6/6 km/h
|
|
Steering angle
|
389
|
|
Tire model
|
23.5-25
|
|
Pattern
|
Herringbone
|
|
Swing angle of front axle:
|
±120
|
|
Winch drive type:.
|
Hydraulic motor drive
|
|
Maximum tractive effort of wirerop
|
204 KN
|
|
Maximum wirerope speed
|
10 m/min
|
|
Drum capacity(diameter X,length)
|
φ22x33 mm/m
|
|
Diameter of winch drum(cable type)
|
273 mm
|
|
Width of winch drum
|
230 mm
|
|
Lifting height of push plate
|
1381 mm
|
|
Earth cutting depth of push pla
|
456 mm
|
|
Turning radius(tire outside)
|
6370 mm
|
|
Overrall width(tire outside)
|
3220 mm
|
|
overrall height(cab)
|
3550 mn
|
|
Tire radius
|
760 mm
|
|
Height of cable frame top abo
|
2700 mm
|
|
Wheelbase
|
3680 mm
|
|
Wheel track
|
2622 mm
|
