Quick Details
-
Max Sewing Speed:
-
1100rpm
-
Max Sewing Thickness:
-
6
-
Voltage:
-
380V,3P,50 HZ ;220V,3P,60HZ
-
Power:
-
4.5KW
-
Dimension(L*W*H):
-
4700*1370*1780mm
-
Weight:
-
3500
-
Model:
-
GM-YS-94
-
Quilt width:
-
2400mm
-
Needlearrangement:
-
76.2+76.2
-
Needlespace:
-
25.4mm
-
Max.horizontalmovement:
-
304.8mm
-
Quiltwidt:
-
≤30mm
-
Stitch:
-
2-7mm
-
Output:
-
60-130m/h
-
Spindle speed:
-
500-1100rpm
-
Voltage(A/C):
-
380V/220V 50HZ/60HZ
Quick Details
-
Marketing Type:
-
New Product 2022
-
Place of Origin:
-
China
-
Brand Name:
-
GENMAX
-
Max Sewing Speed:
-
1100rpm
-
Max Sewing Thickness:
-
6
-
Voltage:
-
380V,3P,50 HZ ;220V,3P,60HZ
-
Power:
-
4.5KW
-
Dimension(L*W*H):
-
4700*1370*1780mm
-
Weight:
-
3500
-
Model:
-
GM-YS-94
-
Quilt width:
-
2400mm
-
Needlearrangement:
-
76.2+76.2
-
Needlespace:
-
25.4mm
-
Max.horizontalmovement:
-
304.8mm
-
Quiltwidt:
-
≤30mm
-
Stitch:
-
2-7mm
-
Output:
-
60-130m/h
-
Spindle speed:
-
500-1100rpm
-
Voltage(A/C):
-
380V/220V 50HZ/60HZ
Products Description
|
Model
|
GM-YS-94
|
|
Overall(Lx WxH)
|
4700*1370*1780mm
|
|
Over all weight
|
3500kg
|
|
Quiltwidth
|
2400mm
|
|
Needlearrangement
|
76.2+76.2
|
|
Needlespace
|
25.4mm
|
|
Max.horizontalmovement
|
304.8mm
|
|
Quiltwidt
|
≤30mm
|
|
Stitch
|
2-7mm
|
|
Output
|
60-130m/h
|
|
Pin type
|
14#-21#
|
|
Spindle speed
|
500-1100rpm
|
|
Voltage(A/C)
|
380V/220V 50HZ/60HZ
|
|
Power
|
4.5KW
|
|
Describe
|
1. The speed of needle is controlled by the computer and can reach 800rpm/min.
2. Needle row movement adopts aluminum alloy needle bar frame structure which doesn’t need to refuel, and will be strong and durable. 3. The saddle frame and roller adopt servo drive equipment, and the spindle adopts frequency conversion control; 4. Adopt high precision and high rigidity imported screw rod; 5. 360°arbitrary quilting and unlimited independent pattern step quilting; 6. Automatic stop function when the upper thread is broken; 7. Infrared induction makes the operation safer; |
FAQ
A)Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
B) Whether you could make your products by our color?
Yes, The color of products can be customized if you can meet our MOQ.
C)How to guarantee the quality of your machine?
1) Strict detection during production.
2) Strict inspection on finished machines before shipment and intact machine packaging ensured.
