Quick Details
-
Storage Type:
-
normal temperature storage
-
The charging ratio:
-
I20
-
The discharge rate:
-
20HR
-
Battery Size:
-
522x240x221mm
-
Brand Name:
-
Techfine or OEM
-
Model Number:
-
GE100-12
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
28.6KG
-
Battery type:
-
AGM,ACID LEAD
-
Voltage:
-
12V
-
Color:
-
Black,Grey,etc
-
Low self-discharge rate:
-
≤3%
-
Teminal:
-
T4
-
Features:
-
Maintenance-free Lead-acid Batteries
-
OEM/ODM:
-
Accept
-
Compliant Standard:
-
IEC,CE,RoHS,ISO
-
Origin:
-
Guangdong China
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Deep Cycle: Sealed AGM
-
Cycle Life:
-
1800 times
-
Storage Type:
-
normal temperature storage
-
The charging ratio:
-
I20
-
The discharge rate:
-
20HR
-
Battery Size:
-
522x240x221mm
-
Brand Name:
-
Techfine or OEM
-
Model Number:
-
GE100-12
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
28.6KG
-
Battery type:
-
AGM,ACID LEAD
-
Voltage:
-
12V
-
Color:
-
Black,Grey,etc
-
Low self-discharge rate:
-
≤3%
-
Teminal:
-
T4
-
Features:
-
Maintenance-free Lead-acid Batteries
-
OEM/ODM:
-
Accept
-
Compliant Standard:
-
IEC,CE,RoHS,ISO
-
Origin:
-
Guangdong China
Why Choose Us
Products Details
Product Parameters
|
Nominal Voltage
|
12V
|
|
|
|
Nominal Capacity(10HR)
|
100AH
|
|
|
|
Dimension
|
Length
|
330 ±3mm (12.99 inches)
|
|
|
|
Width
|
173 ±2mm (6.81 inches)
|
|
|
|
Container Height
|
214 ±2mm (8.43 inches)
|
|
|
|
Total Height (withTerminal)
|
243±2mm (9.57 inches)
|
|
|
Approx Weight
|
Approx 27.7 kg (61.07lbs)
|
|
|
|
Terminal
|
T11
|
|
|
|
Container Material
|
ABS
|
|
|
|
Rated Capacity
|
104.0 AH/5.20A
|
(20hr ,1.80V/cell,25℃/77℉)
|
|
|
|
100.0 AH/10.0A
|
(10hr,1.80V/cell,25℃/77℉)
|
|
|
|
86.0 AH/17.2A
|
(5hr,1.75V/cell,25℃/77℉)
|
|
|
|
78.0 AH/26.0A
|
(3hr,1.75V/cell,25℃/77℉)
|
|
|
|
61.0 AH/61.0A
|
(1hr,1.60V/cell,25℃/77℉)
|
|
|
Max. Discharge Current
|
1200A (5s)
|
|
|
|
Internal Resistance
|
Approx 4.8mΩ
|
|
|
|
Operating Temp.Range
|
Discharge : -15~50℃ (5~122℉)
|
|
|
|
|
Charge : 0~40℃ (32~104℉)
|
|
|
|
|
Aircraft signal Storage : -15~40℃ (5~104℉)
|
|
|
|
Nominal Operating Temp. Range
|
25 ±3℃ (77 ±5℉ )
|
|
|
|
Cycle Use
|
Initial Charging Current less than 30.0A.Voltage Communication power supply 14.4V~15.0V at 25℃(77℉)Temp. Coefficient -30mV/℃
|
|
|
|
Standby Use
|
No limit on Initial Charging Current Voltage Auto controlsystem 13.5V~13.8V at 25℃(77℉)Temp. Coefficient -20mV/℃
|
|
|
|
Capacity affectedby Temperature
|
40℃ (104 ℉)103%
|
|
|
|
|
25℃ ( 77 ℉ )100%
|
|
|
|
|
0℃ ( 32℉ ) 86%
|
|
|
|
Self Discharge
|
Techfine batteries may be stored for up to 6 months at 25℃(77℉) and battery should be recharge before use . For higher
temperatures the time interval will be shorter. |
|
|
