Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ORIEMAC
-
Engine model:
-
WD615.69
-
Rated power (kw/rpm):
-
336HP
-
Wheel Base:
-
4600+1350mm
-
Curb Weight:
-
220
-
Max Speed:
-
90Km/h
-
Transmission:
-
HW19710
-
Tyre:
-
12.00R20
-
Container Volume:
-
24m3
-
Sewage tanker:
-
200L
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Japan, Malaysia, Australia, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service
-
Certification:
-
ISO
Quick Details
-
Engine Capacity:
-
9726ml
-
Size:
-
11500*2500*3600mm
-
Gross Vehicle Weight:
-
15000
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ORIEMAC
-
Engine model:
-
WD615.69
-
Rated power (kw/rpm):
-
336HP
-
Wheel Base:
-
4600+1350mm
-
Curb Weight:
-
220
-
Max Speed:
-
90Km/h
-
Transmission:
-
HW19710
-
Tyre:
-
12.00R20
-
Container Volume:
-
24m3
-
Sewage tanker:
-
200L
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Japan, Malaysia, Australia, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service
-
Certification:
-
ISO
|
1: Can choose 240L ( single bin. double bins) or 360L. 660L.standard bin lifting and turnover mechanism, can also choose ground hopper and other kinds of loading mechanism. 2: With manual and automatic two sets of control method, the operator can control in the cabin, in the middle side or the back of the truck , very convenient and efficient. 3: With working device of emergency braking stop button. 4: Garbage body use frame design, elegant, strong structure, large effective capacity. 5: Equipped with special collection box, sewage directly into the sewage tank inthe process of compression, that is effectively prevent second pollution caused by sewage leaks. |
6: Through hydraulic system design, the truck achieve the function of two-way garbage compression, that is improve the compressibility,make the compression ratio up to 1:2.5,the garbage can reach more then 600~ 800kg/ m3 after compression.
|
Basic Information |
|
|
Chassis brand |
HOWO Brand,ZZ1257 |
|
Product |
HOWO 6x4 24m3 garbage Compactor truck |
|
Overall Dimension |
|
|
Cab |
Single Row with one sleeper |
|
Driver position |
Left hand drive |
|
Drive Model |
6X4 |
|
Overall Parameter: L × W × H |
11500 × 2500 × 3600mm |
|
Wheel Base |
4600+1350mm |
|
Curb Weight |
15000kg |
|
Max Speed |
90Km/h |
|
Engine and Chassis |
|
|
Engine manufacturer |
China national heavy duty truck group |
|
Engine type |
WD615.69 |
|
Power |
336HP |
|
Displacement |
9726ml |
|
Emission Standard |
Euro 2 |
|
Transmission |
HW19710,10 speed Manual Transmission |
|
Front axle |
HF9, 9Tons |
|
Rear axle |
HC16, 16Tons double |
|
Suspension System |
Leaf spring,10/12 |
|
Tyre |
12.00R20,Radial tire,10+1 |
|
Usage Parameter |
|
|
Container Volume |
24m3 |
|
Sewage tanker |
200L |
|
Steel and thickness |
5mm/Q345 |
|
Unloading Model |
Push out |
|
Feed in one cycle working time |
≤ 10s |
|
Feed out one cycle working time |
≤ 35s |
|
Hydraulic system pressure |
16Mpa |
|
Control method |
Both manual and electric control |
|
Color + customer logo |
As requirement |
