Quick Details
-
Power:
-
20000
-
Dimension(L*W*H):
-
L19500 x W3500 x H2200mm
-
Weight:
-
1000
-
Control system:
-
Multi-Axis Motion Controlle
-
Controller&PLC Drive element:
-
Servo motor
-
Operate interface:
-
10LCD touch screen
-
Cutting:
-
Synchronous roller Cutter
-
Packing style:
-
Aulomalic packing machine full servo reciprocating
-
Material connection:
-
Nonwoven. film. label
-
Flow control:
-
Frequency converter control
-
Joint detection:
-
Detection online
-
Folding type:
-
Interfold type & single extraction
-
Option equipment:
-
Coding machine,Metal detection online
Quick Details
-
Place of Origin:
-
Zhengzhou, China
-
Brand Name:
-
LUCHUANG
-
Voltage:
-
380v
-
Power:
-
20000
-
Dimension(L*W*H):
-
L19500 x W3500 x H2200mm
-
Weight:
-
1000
-
Control system:
-
Multi-Axis Motion Controlle
-
Controller&PLC Drive element:
-
Servo motor
-
Operate interface:
-
10LCD touch screen
-
Cutting:
-
Synchronous roller Cutter
-
Packing style:
-
Aulomalic packing machine full servo reciprocating
-
Material connection:
-
Nonwoven. film. label
-
Flow control:
-
Frequency converter control
-
Joint detection:
-
Detection online
-
Folding type:
-
Interfold type & single extraction
-
Option equipment:
-
Coding machine,Metal detection online
|
Suitable material
|
Spunlaced nonwoven. air-laid nonwovens. nonwovens etc.
|
|
Unit weight of material
|
35 -60g/m2
|
|
Raw material specification
|
W2 10mmx2, ∅1200mm (Optiona Large wolume Automatic cutting W800- 1200mm,∅1200mm)
|
|
Folding type
|
Interfold type & single extraction
|
|
Open size
|
L120-220mm x W150-300mm
|
|
Wet wipes size
|
L120- 220mm x W90- 120mm
|
|
Moisture type
|
Fluid pipes spray independenty
|
|
Flow control
|
2.5-4.5times flow meter control
|
|
Cutting
|
Synchronous rller Cutter
|
|
Stacking mode
|
Servo motor Independent control
|
|
Folding form
|
30- 120sheets
|
|
Packing style
|
Automatic packing machine full servo reciprocating
|
|
Open hole Labeling
|
Synchronization Open hole doubleLabeling
|
|
Packing film speitication
|
Double packaging film Max diameter380mm W450mm
|
|
Packing film connection
|
Automatic roll changing without stopping machine
|
|
Package size
|
L100-330mm, W95-140mm, H10-90mm
|
|
Production speed
|
Fol4000-6500pieces/min, Packing40-80bag/min
|
|
Power
|
AC380V 50/60Hz 20KW
|
|
Overall dimensions
|
L19500 x W3500 x H2200mm
|
|
Machine net weight
|
8000kg
|
Details Images
Non-woven automatic unwinding→ automatic connection→ constant tension control→ sub-width folding→ traction feeding→ 20-lane confluence→ quantitative humidification and cutting→ stacking counting→ synchronous conveying→ automatic packaging machine Roll film unwinding→automatic opening→automatic labeling (double labeling)→heat sealing and cutting (back sealing+horizontal sealing)→automatic gusset→product air pressure→finished product output→2m finished product conveyor → lid applicator
The electrical, robot, switch and other brands of our equipment are mainly Schneider, Mitsubishi, Siemens, Omron, Yaskawa, Panasonic and other internationally renowned brands.
The material of our equipment, especially the blade part and the parts in contact with the liquid, are mainly 304/316L stainless steel; the bearings are also internationally renowned brands such as NTN and NSK.
Please kindly inform us the details of your final product requirements, the professional solutions and customized services will be provided then.
The company is an intelligent wet tissue equipment manufacturer integrating R&D, production, sales and technical services. The main employees of the company are all professional and technical personnel with 10-20 years of experience in the industry. In addition to providing customers with high-quality equipment, they also include project planning, program consultation, workshop design and supporting information provision and other services.
The company has a product research and development center, an ERP management system, and has continuously launched the "LC" series of automatic wet wipes production lines with intellectual property rights. The company has passed ISO9001:2015 quality system certification, and has become a national high-tech enterprise GR202141001017.
The company's main products include automatic baby wipes production line, portable wipes production line, single-piece wipes production line, robotic wet wipes capping machine, barreled wet wipes production line, robotic case packing machine, robotic palletizer and other equipment and packaging equipment.
The advantages of our company are as follows:
1. A professional R&D team with 10-20 years of industry experience;
2. Cooperated brands of wet wipes includes Johnson's, einb, Combi, Babycare, Deyou, etc.;
3. Mainly brands of electrical parts are Siemens, Mitsubishi, Omron, Yaskawa, Panasonic, Trio, etc.;
4. Raw material of the main parts is 304/316L stainless steel;
5. Currently has 27 national patents, as well as certificates of CE, ISO9001, IPMS, etc.
