Quick Details
-
Luminous Efficacy(lm/w):
-
120
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FLOHAR
-
Product name:
-
Street light pole
-
Height(m):
-
4-15m(can be customized)
-
Dia.(mm):
-
60*140(can be customized)
-
Thickness(mm):
-
2.75mm(can be customized)
-
Flange(mm):
-
260*260*12(can be customized)
-
Arm length(mm):
-
800(can be customized)
-
Light source power(w):
-
30(can be customized)
-
Pole Weight (kg):
-
48.78(can be customized)
-
Life span:
-
20 years
-
Certification:
-
CE ISO9001 ISO14000 ISO18000 CQC ROHS
Quick Details
-
Material:
-
Steel
-
Type:
-
Round
-
Application:
-
Highway/Country/Commerial block
-
Luminous Efficacy(lm/w):
-
120
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FLOHAR
-
Product name:
-
Street light pole
-
Height(m):
-
4-15m(can be customized)
-
Dia.(mm):
-
60*140(can be customized)
-
Thickness(mm):
-
2.75mm(can be customized)
-
Flange(mm):
-
260*260*12(can be customized)
-
Arm length(mm):
-
800(can be customized)
-
Light source power(w):
-
30(can be customized)
-
Pole Weight (kg):
-
48.78(can be customized)
-
Life span:
-
20 years
-
Certification:
-
CE ISO9001 ISO14000 ISO18000 CQC ROHS
Data Sheet
| Height(m) | Dia.(mm) | Thickness(mm) | Flange(mm) | Arm length(mm) |
Light source
power(w) |
Pole
Weight (kg) |
| 5 | 60*140 | 2.75 | 240*240*12 | 800 | 30 | 41.24 |
| 6 | 60*140 | 2.75 | 260*260*12 | 800 | 30 | 48.78 |
| 7 | 80*160 | 3 | 280*280*14 | 1000 | 40 | 72.75 |
| 8 | 90*170 | 3.25 | 300*300*14 | 1000 | 40 | 94.71 |
| 9 | 90*180 | 3.25 | 350*350*16 | 1200 | 60 | 114.68 |
| 10 | 100*200 | 3.5 | 400*400*18 | 1200 | 80 | 153.31 |
| >10 |
Hot dip galvanized steel street light pole
♦
Light pole was designed by anti-seismic 7 degrees & anti-wind 11 level & anti-seismic intensity is B level.
♦
According to the design requirements,the light pole material is made of high quality low carbon steel Q235,and the silicon content of stee isnot higher than 0.04%.Bending forming by a large bending machine,straigtness error is not more than 0.05%.
♦ Manufacturing technology:The light pole is formed integrally with smooth line,treated with internal and external hot galvanizing.The process of galvanizing is acid washing,hot galvanizing,washing,passivation and so on.Conforms to the national standard GB/T13912-92.Zinc plating adhesion,conforms to the standard GB2694-88 request,the anticorrosion life is more than 30 years.
|
Company services: |
|
|
1. |
The company can provide solutions for the application of solar street lamps, high-rod lamps, LED street lamps, complementary lighting lamps, solar wind hybrid street light and industrial and mining lamps. |
|
2. |
Optimized product parameters according to customers' specific needs, and provided the best product design scheme. |
|
3. |
Organize production, transportation, installation, commissioning, personnel training and maintenance during the guarantee period. |
|
4. |
Provide the authoritative testing report of products and other technical support. |
Q1:Can I have a sample order for lighting pole?
A:Yes,welcome sample order for testing and checking,mixed samples available.
Q2:Do you accept OEM/ODM?
A:Yes,we’re factory with standard production lines to fulfill different requirements from our clients.
Q3:What about the lead time?
A: Sample needs 3-5 days, bulk order need 1-2 weeks, if quantity more than 1000 sets 2-3 weeks.
Q4:How about your MOQ limit?
A:Low MOQ, 1pcs for sample checking available.
Q5:Guarantee for the products?
A:Usually 3-10 years for the lighting pole.
Q6:How to deal with the quality fault?
A:We use Q235 steel, processed with hot-dip galvanizing, spray-painting, high quality, guaranteed quality. In case of quality issue, during warranty period, all parts can be changed or replaced in any case of quality damage.
