Quick Details
-
Warranty:
-
180000kms on normal road within one year
-
Tread:
-
Four steel plys
-
Sidewall:
-
One steel ply
-
Market:
-
Mid-east, Europe, Africa, America
-
Certifications:
-
DOT, ECE, GCC, SONCAP, INMETRO, ELABLE
-
Natural rubber:
-
From Thailand, Vietnam
-
Max Load:
-
3500kg/3150kg
-
Weight:
-
60kg
-
Tread Depth:
-
17-24mm
-
Inflation Pressure:
-
900kpa
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Haida
-
Model Number:
-
315/70 R 22.5
-
Warranty:
-
180000kms on normal road within one year
-
Tread:
-
Four steel plys
-
Sidewall:
-
One steel ply
-
Market:
-
Mid-east, Europe, Africa, America
-
Certifications:
-
DOT, ECE, GCC, SONCAP, INMETRO, ELABLE
-
Natural rubber:
-
From Thailand, Vietnam
-
Max Load:
-
3500kg/3150kg
-
Weight:
-
60kg
-
Tread Depth:
-
17-24mm
-
Inflation Pressure:
-
900kpa
Top quality.!!! 3 Years Factory Warranty!
- Well-balanced tire with superior performance to create longer tire life and
- excellent handling capabilities on wet or dry road surfaces
- Integrated Decoupling Groove and Tread Rib Protectors help educe irregular wear patterns
- The all-steel casing design promotes durability and retread ability
- Recommended for steering axle of trucks, buses
Advantage
<1> Guaranteed quality: All materials are best (Natural rubber from Malaysia; Carbon black are from CABOT,USA; And steel cord are from BEKAERT,BELGIUM). Equipment are from Germany,Holland,Japan. High Technology to ensure tire performance outstanding.
<2> Fast delivery time: stock: 7-10 days production: 15-20 days
<3> Good service for before & after sales.
<4> Reasonable price for long term relationship
|
Size |
Ply Rating |
Depth(MM) |
Load&Speed Index |
Standard RiM |
Max Load/Max Pressure Single Dual |
Inflated DiMensions(MM) Section Overall |
|
11R22.5 |
16 |
15.00 |
146/143 M |
8.25 |
6175(LB)/105(PSI) 5840(LB)/105(PSI) |
279 1050 |
|
11R24.5 |
16 |
15.00 |
149/146 M |
8.25 |
6610(LB)/105(PSI) 6005(LB)/105(PSI) |
279 1104 |
|
275/70R22.5 |
16 |
15.00 |
148/145 M |
8.25 |
6945(LB)/130(PSI) 6395(LB)/130(PSI) |
276 958 |
|
285/75R24.5 |
14 |
15.00 |
144/141 M |
8.25 |
6175(LB)/110(PSI) 5675(LB)/110(PSI) |
285 1050 |
|
295/75R22.5 |
14 |
15.00 |
144/141 M |
8.25 |
6175(LB)/110(PSI) 5675(LB)/110(PSI) |
295 1014 |
|
Size |
Ply Rating |
Depth(MM) |
Load&Speed Index |
Standard RiM |
Max Load/Max Pressure Single Dual |
Inflated DiMensions(MM) Section Overall |
|
9.00R20 |
16 |
15.00 |
144/142 L |
7.00 |
2800(Kg)/900(kpa) 2650(Kg)/900(kpa) |
259 1019 |
|
10.00R20 |
16 |
15.50 |
146/143 L |
7.50 |
3000(kg)/830(kpa) 2725(kg)/830(kpa) |
278 1055 |
|
11.00R20 |
16 |
16.00 |
150/147 L |
8.00 |
3350(kg)/930(kpa) 3250(kg)/930(kpa) |
293 1085 |
|
11R22.5 |
16 |
15.50 |
146/143 M |
8.25 |
2803(kg)/725(kpa) 2650(kg)/725(kpa) |
279 1054 |
|
11R24.5 |
16 |
15.50 |
149/146 M |
8.25 |
3000(kg)/725(kpa) 2725(kg)/725(kpa) |
279 1104 |
|
295/80R22.5 |
16 |
16.00 |
152/148 |
9.00 |
3270(kg)/850(kpa) 2900(kg)/850(kpa) |
298 1044 |
|
Size |
Ply Rating |
Depth(MM) |
Load&Speed Index |
Standard RiM |
Max Load/Max Pressure Single Dual |
Inflated DiMensions(MM) Section Overall |
|
385/65R22.5 |
20 |
16.00 |
156/150 K |
11.75 |
4250(kg)/850(kpa) |
389 1072 |
|
425/65R22.5 |
20 |
17.00 |
165 K |
13.00 |
4750(kg)/760(kpa)
|
422 1124 |
|
Size |
Ply Rating |
Depth(MM) |
Load&Speed Index |
Standard RiM |
Max Load/Max Pressure Single Dual |
Inflated DiMensions(MM) Section Overall |
|
12.00R20 |
18 |
17.00 |
154/151 K |
8.50 |
3750(kg)/830(kpa) 3450(kg)/830(kpa) |
315 1125 |
|
12.00R24 |
20 |
17.50 |
160/157 K |
8.50 |
4500(kg)/900(kpa) 4125(kg)/900(kpa) |
315 1226 |
|
315/80R22.5 |
20 |
16.50 |
156/150 L |
9.00 |
4000(kg)/860(kpa) 3520(kg)/860(kpa)
|
