Quick Details
-
Jacket:
-
PVC
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
jinkai
-
Model Number:
-
AVSS car wire
-
Product name:
-
car wire
-
Color:
-
Black,red,yellow,blue,green,etc
-
Conductor:
-
copper
-
Insulation:
-
PVC
-
Core:
-
1 core
-
Working temperature:
-
-40 --+85
Quick Details
-
Insulation Material:
-
PVC
-
Application:
-
car
-
Conductor Material:
-
Copper
-
Jacket:
-
PVC
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
jinkai
-
Model Number:
-
AVSS car wire
-
Product name:
-
car wire
-
Color:
-
Black,red,yellow,blue,green,etc
-
Conductor:
-
copper
-
Insulation:
-
PVC
-
Core:
-
1 core
-
Working temperature:
-
-40 --+85
Product Structure
Product Advantages
Product Paramenters
|
conductor
|
Cu-ETP1 bare copper conforms to JIS 3120 standard
|
|
insulation
|
PVC
|
|
standard
|
ISO 6722 Class B
|
|
technical parameter
|
–40 °C - 85 °C
|
|
conductor
|
|
|
Insulation
|
Cabling
|
|
|
|
||||
|
Nominal conductor cross-sectional area
|
Number of strands
/diameter
|
Maximum diameter
|
Maximum resistance at 20 ° C
|
Insulation thickness
|
Minimum outside diameter
|
Maximum outside diameter
|
weight
|
||||
|
MM2
|
NO./MM
|
(MM)
|
MΩ/M
|
(MM)
|
MM
|
MM
|
KG/KM
|
||||
|
1 x 0.30
|
7/0.26
|
0.8
|
50.2
|
0.3
|
1.4
|
1.5
|
5
|
||||
|
1 x 0.50
|
7/0.32
|
1
|
32.7
|
0.3
|
1.6
|
1.7
|
7
|
||||
|
1 x 0.85
|
19/0.24
|
1.2
|
21.7
|
0.3
|
1.8
|
1.9
|
10
|
||||
|
1 x 1.25
|
19/0.29
|
1.5
|
14.9
|
0.3
|
2.1
|
2.2
|
14
|
||||
|
1 x 0.3f
|
19/0.16
|
0.8
|
48.8
|
0.3
|
1.4
|
1.5
|
5
|
||||
|
1 x 0.5f
|
19/0.19
|
1
|
34.6
|
0.3
|
1.6
|
1.7
|
7
|
||||
|
1 x 0.75f
|
19/0.23
|
1.2
|
23.6
|
0.3
|
1.8
|
1.9
|
10
|
||||
|
1 x 1.25f
|
37/0.21
|
1.5
|
14.6
|
0.3
|
2.1
|
2.2
|
14
|
||||
|
1 x 2f
|
37/0.26
|
1.8
|
9.5
|
0.4
|
2.6
|
2.7
|
22
|
||||
