Quick Details
-
Brand Name:
-
Snow-Sea
-
Use:
-
FTTH
-
Warranty Time:
-
2 years
-
Network:
-
FTTH
-
Cable Length (M):
-
1//3/5/10/15/30M or desired the length of cable shall be supplier
-
Fiber Type:
-
Corning SMF-28TM, 9/125um (SM), 50/125um or 62.5/125um(MM)
-
Operating Temperature:
-
-40~+80 °C
-
Storage Temperature:
-
-40~+85 °C
-
Durability:
-
>1000 times
-
Industry Standard:
-
Telcordia GR-326-CORE
-
Cable Diameter (mm):
-
0.9 2.0 2.4 3.0mm, Simplex, Duplex
-
Insertion Loss:
-
≤0.20
-
Repeatability:
-
≤0.10
-
Exchangeability:
-
≤0.20
Quick Details
-
Type:
-
Fiber Pigtails
-
Model Number:
-
AFOPC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Snow-Sea
-
Use:
-
FTTH
-
Warranty Time:
-
2 years
-
Network:
-
FTTH
-
Cable Length (M):
-
1//3/5/10/15/30M or desired the length of cable shall be supplier
-
Fiber Type:
-
Corning SMF-28TM, 9/125um (SM), 50/125um or 62.5/125um(MM)
-
Operating Temperature:
-
-40~+80 °C
-
Storage Temperature:
-
-40~+85 °C
-
Durability:
-
>1000 times
-
Industry Standard:
-
Telcordia GR-326-CORE
-
Cable Diameter (mm):
-
0.9 2.0 2.4 3.0mm, Simplex, Duplex
-
Insertion Loss:
-
≤0.20
-
Repeatability:
-
≤0.10
-
Exchangeability:
-
≤0.20
Anti Rat Bite Armoured Fiber Optic Patch Cord with SC/FC/LC/ST Connector
Description
Armoured fi ber optic patch cord and traditional fiber optic patch cord the biggest difference is that it uses a small bypass pipe and a woven metal mesh to protect the optical fiber according to fiber easy broken, easy damage defects,, and flame retardant PVC protective sheath, in order to achieve the purpose of moistureproof fireproof and prevention of rat bite. It can be directly laid in the network room and other harsh environments, without the use of protective sleeves for saving space. Armored cable structure as follows: 0.6 tightly fiber + metal hose + Dupont Kevlar+ woven metal wire (reinforced cable torsion function, to prevent external damage to cable ) + environmental flame retardant PVC, than cable strength greater than the general indoor cable. It c an prevent rat bite, compressive, tensile, meet the harsh working environment. Greatly enhance the network maintenance convenience.
Features
Low Insertion Loss
High Return Loss
Good Repeatability
Good Exchangeability
High Temperature Stability
Comply with YD/T 1272.4-2007 specification
8° Angled physical contact polishing (APC)
Applications
Optic-fiber Communication Systems
Optic-fiber Data Communications
Optic-fiber Access Networks
Optic-fiber CATV
LAN
Test Equipment
Optic-fiber Sensors
Specifications
|
Item |
Unit |
FC,SC,ST/PC |
FC,SC,ST/UPC |
FC,SC,ST/APC |
|
Insertion Loss |
dB |
≤0.20 |
≤0.20 |
≤0.30 |
|
Repeatability |
dB |
≤0.10 |
||
|
Exchangeability |
dB |
≤0.20 |
||
|
Return Loss |
dB |
≥50(SM) |
≥55(SM) |
≥60(SM) |
|
Fiber Type |
|
Corning SMF-28TM, 9/125um (SM), 50/125um or 62.5/125um(MM) |
||
|
Operating Temperature |
°C |
-40~+80 |
||
|
°C |
-40~+85 |
|||
|
Durability |
time |
>1000 times |
||
|
Industry Standard |
Telcordia GR-326-CORE |
|||
|
Cable Diameter (mm) |
0.9 2.0 2.4 3.0mm, Simplex, Duplex |
|||
|
Cable Length (M) |
1M 2M 3M 5M 7M 10M 15M 20M 30M or desired the length of cable shall be supplier |
|||
Note:
Specifications of each type patch cord cannot be listed here one by one because of variety of different kinds of patch cords. So please kindly to contact us for any more details!
