Quick Details
-
Lamp Body Material:
-
titanium alloy
-
Lamp Luminous Flux(lm):
-
1300
-
Color Temperature(CCT):
-
2700-5700K
-
Input Voltage(V):
-
3-4.2V
-
Product Weight（kg）:
-
0.125
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Convoy
-
Model Number:
-
S2+
-
zoomable:
-
no
Quick Details
-
Battery Type:
-
18650
-
Use:
-
Emergency
-
Power Source:
-
rechargeable battery
-
Lamp Body Material:
-
titanium alloy
-
Lamp Luminous Flux(lm):
-
1300
-
Color Temperature(CCT):
-
2700-5700K
-
Input Voltage(V):
-
3-4.2V
-
Product Weight（kg）:
-
0.125
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Convoy
-
Model Number:
-
S2+
-
zoomable:
-
no
PARAMETER
Material : Titanium alloy
LED: Nichia 519A R9080 high CRI , SST40, SFT40 ,with DTP copper plate
Driver: 5A current 12groups
Low volta ge warning : Yes
Reverse polarity protection: Yes
Lens type: Ar-coated Glass
Reflector: orange peel for 519A, smooth for SST40 SFT40,
Mode memory: Yes
Tailstand: Yes
Battery included: No
Required battery type: unprotected 18650 lithium battery which can bear 5amps current
Required battery quantity: 1pcs
Height: 118mm
Width: 24.1mm
Weight: 125g
Mode Instruction:
12 groups:
1.click the switch to turn the flashlight on/off,tap the switch to select mode
2.if flashlight is turned on,tap the switch 20 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and "tap the switch in the flashing process" means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
-------------sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (0.1%, 1%, 10%, 35%, 100%, strobe, biking, battery-check)
-------------sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (0.1%, 1%, 10%, 35%, 100%)
-------------sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%, 35%, 10%, 1%, 0.1%)
-------------sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%, 20%, 100%, strobe, biking, battery-check, SOS)
-------------sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%, 20%, 100%)
-------------sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%, 20%, 1%)
-------------sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (0.1%, 1%, 10%, 50%, strobe, biking, battery-check, SOS)
-------------sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(0.1%, 1%, 10%, 50%)
-------------sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%, 10%, 1%, 0.1%)
-------------sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (1%, 10%, 35%, 100%)
-------------sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%, 20%, strobe)
-------------sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100% only)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
battery-check instructions:
<2.95V 1 flash,
2.95-3.25V 2 flashes,
3.25-3.55V 3 flashes,
3.55-3.85V 4 flashes,
>3.85V 5 flashes
