Quick Details
-
Input Voltage(V):
-
220-240VAC
-
Lamp Luminous Flux(lm):
-
1800lm
-
Model Number:
-
PZ-4-20W
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LHWYLED
-
Keyword:
-
recessed mr16 gu10 downlights
-
Power:
-
20W
-
Dimension:
-
D50*H102mm
-
LED Chip:
-
Cree COB
-
Color Temperature(CCT):
-
2700K/3000K/3500K/4000K/ 5000K/5700K/6500K
-
Input Voltage:
-
220-240VAC
-
Beam Angle:
-
15/25/38/60°
-
Material:
-
Aluminum Heat Sink+Clear/Frosted PC Cover/Lens/Honeycomb
-
Usage:
-
MR16 MR11 GU10 GU5.3 Replacement
-
Installation:
-
Recessed Downlight Retrofit
-
Luminous Efficacy(lm/w):
-
100
-
Working Lifetime(Hour):
-
50000
Quick Details
-
Lamp Body Material:
-
Aluminum
-
Install Style:
-
Downlights
-
Warranty(Year):
-
3-Year
-
Input Voltage(V):
-
220-240VAC
-
Lamp Luminous Flux(lm):
-
1800lm
-
Model Number:
-
PZ-4-20W
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LHWYLED
-
Keyword:
-
recessed mr16 gu10 downlights
-
Power:
-
20W
-
Dimension:
-
D50*H102mm
-
LED Chip:
-
Cree COB
-
Color Temperature(CCT):
-
2700K/3000K/3500K/4000K/ 5000K/5700K/6500K
-
Input Voltage:
-
220-240VAC
-
Beam Angle:
-
15/25/38/60°
-
Material:
-
Aluminum Heat Sink+Clear/Frosted PC Cover/Lens/Honeycomb
-
Usage:
-
MR16 MR11 GU10 GU5.3 Replacement
-
Installation:
-
Recessed Downlight Retrofit
-
Luminous Efficacy(lm/w):
-
100
-
Working Lifetime(Hour):
-
50000
Product Description
This Recessed MR16 GU10 Downlight is to replace all halogen bulbs which diameter is 50mm, such as MR16 MR11 GU10 GU5.3. And we have 3w 5w 7w 8w 9w 10w 12w 15w 18w 20w whole series.
This item
mr16 downlight
advantages:
1. More beam angle by reflector: 15/25/38/60°; 2. More beam angle by lens: 10/23/36°;
3. The PC Cover can be clear, dot, sandy design;
4. The honeycomb cover is available too; 4. Replace all MR16 MR11 GU10 G5.3 Bulbs;
5. Best price good quality ready to ship;
6. Fast lead time: 1-3 days for under 500pcs;
7. High quality with CREE/ Citizen/Osram/Philips LED chip and Philips/Osram/Tridonic/LIFUD driver; 8. Other dimming type: 0-10V/Triac/Dali/Dmx/Push Dim/ CCT Tunable all available;
This is the parameters of mr16 led downlight series:
|
Model No.
|
Power
|
Lumen
|
LED Chip
|
CRI
|
CCT
|
LED Driver
|
Size
|
|
PZ-4-5W
|
5W
|
450lm
|
CREE CXA1304
|
RA>90
RA>95
|
2700K
3000K
3500K
4000K
5000K
5700K
6500K
|
XY LED Driver
Philips Driver
Tridonic Driver
Osram Driver
Lifud Driver
0-10V Driver
Triac Dimming
LTECH
DALI Dimmable
|
D50*H33mm
|
|
PZ-4-7W
|
7W
|
650lm
|
CREE CXA1304
|
|
|
|
D50*H43mm
|
|
PZ-4-10W
|
10W
|
900lm
|
CREE CXA1507
|
|
|
|
D50*H58mm
|
|
PZ-4-15W
|
15W
|
1300lm
|
CREE CXA1512
|
|
|
|
D50*H76mm
|
|
PZ-4-20W
|
20W
|
1800lm
|
CREE CXA1512
|
|
|
|
50*H105mm
|
Details Images
MR16 Recessed Downlight Project Cases
This
LED MR16 module ceiling downlight
is widesly used in home. hotel, shop, small room, residential, it has the power 3w 5w 7w 10w 15w and max 20w, cutout is just 75mm. All this design can replace the MR16 GU10 halogen spotlight. And beam angle can be 15/25/38/60 degree.
Product packaging
The 20W
MR16
Module Package:
1. Inner Box Size: 12*12*5mm;
2. Net weight: 0.30kgs/pcs;
3. Quantity: 54pcs/ctn;
4. Carton size: 46*46*25cm;
5. Gross weight: 17.5kgs
6. Customized package/logo/Laser welcome;
7. Thicken K+K Carton Box;
8. Neutral Standard Package as standard pack;
