The CES-LN-02P series is widely used in the hazardous locations, such as gas station, factory workshop, petrochemical plant and so on.
It is the most popular product in our company, this product is a high sales volume of our company every year. As picture showed is LN-02P Linear light for LNG plant in Singapore, it is also used in an
China National Offshore Oil Corporation Lighting Engineering Project - CNOOC
. The image below is a physical images of all kinds of projects.
- Product Details
- {{item.text}}
Quick Details
-
Light Source:
-
LED
-
Color Temperature(CCT):
-
6500K
-
Input Voltage(V):
-
AC120-277V(50/60Hz) or DC12-24V
-
Product Weight（kg）:
-
4.2
-
CRI (Ra>):
-
72
-
Lamp Luminous Flux(lm):
-
3200
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CESP
-
Product Name:
-
Explosion Proof Lighting Fixture
-
Warranty:
-
5 Years
-
Driver:
-
Meanwell
-
Beam angle:
-
180 360 Degree
-
Color:
-
Black, Yellow
-
IP Grade:
-
IP66
-
Housing:
-
Heavy duty copper free aluminum alloy housing, ABS+PC handle
-
Application:
-
Class I Div 1 Hazarous Areas
-
EX Code:
-
Ex d IIB T6 Gb/Ex tb IIIC T85°C Db
-
LED Light Source:
-
LED
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
120
-
Warranty(Year):
-
5-Year
-
Working Temperature(℃):
-
-40 - 50
-
Light Source:
-
LED
-
Color Temperature(CCT):
-
6500K
-
Input Voltage(V):
-
AC120-277V(50/60Hz) or DC12-24V
-
Product Weight（kg）:
-
4.2
-
CRI (Ra>):
-
72
-
Lamp Luminous Flux(lm):
-
3200
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CESP
-
Product Name:
-
Explosion Proof Lighting Fixture
-
Warranty:
-
5 Years
-
Driver:
-
Meanwell
-
Beam angle:
-
180 360 Degree
-
Color:
-
Black, Yellow
-
IP Grade:
-
IP66
-
Housing:
-
Heavy duty copper free aluminum alloy housing, ABS+PC handle
-
Application:
-
Class I Div 1 Hazarous Areas
-
EX Code:
-
Ex d IIB T6 Gb/Ex tb IIIC T85°C Db
-
LED Light Source:
-
LED
Product Description
Product Paramenters
|
Model
|
(w)
|
Input voltage: AC 120 V
|
|
|
|
|
|
|
|
|||||||
|
|
|
Output voltage, 30-36 Vdc
|
|
|
|
|
|
|
|
|||||||
|
|
|
CCT, 3000 K/4000 K/6500K
|
|
|
|
|
|
|
|
|||||||
|
|
|
Power factor : 0.97
|
|
|
|
|
|
|
|
|||||||
|
|
|
LED Type : (3 V , 1 W ) 3030
|
|
|
|
|
|
|
|
|||||||
|
|
|
Input
voltage (V)
|
Output current
(A)
|
Input current
(A)
|
Luminous flux(LM)
|
Light efficiency
(Lm /W)
|
LEDs chip
|
Hazardous
Location
|
Weights (kg)
|
|||||||
|
CES-SC30
|
30
|
AC 120 V
|
0.8 A
|
0.3A-0.12A
|
3900
|
100
|
72Pcs
|
Class 1 Divsion 1 & 2
(ATEX and IECEx Zone 1, Please see CES-EX-SC Series)
|
2.4
|
|||||||
|
|
|
AC 120 V
|
|
0.28A
|
|
|
|
|
|
|||||||
|
|
|
AC 120 V
|
|
2.5A-1.25A
|
|
|
|
|
|
|||||||
|
|
20
|
AC 100V-277V
|
0.48A
|
0.2A-0.08A
|
2600
|
|
|
|
|
|||||||
|
|
|
DC 110V
|
|
0.18A
|
|
|
|
|
|
|||||||
|
|
|
DC 12V-24V
|
|
1.7A-0./A
|
|
|
|
|
|
|||||||
|
|
10
|
AC 100V-277V
|
0.23A
|
0.1A-0.
04A
|
1300
|
|
|
|
|
|||||||
|
|
|
DC 110V
|
|
0.09A
|
|
|
|
|
|
|||||||
|
|
|
DC 12V-24V
|
|
0.8A-0.4A
|
|
|
|
|
|
|||||||
T-Class
|
Ta
Model
|
Ambient temperature range
|
|
|
|
|||
|
|
Class I
|
|
|
Class II and Class III
|
|||
|
|
-40°C ~ 40°C
|
-40°C ~ 45°C
|
-40°C ~ 50°C
|
-40°C ~ 50°C
|
|||
|
CES-EX-GB-02-200
|
T3C
|
T3C
|
T3C
|
88°C
|
|||
|
CES-EX-GB-02-185
|
T4
|
T4
|
T4
|
88°C
|
|||
|
CES-EX-GB-02-150
|
T4A
|
T4A
|
T4
|
88°C
|
|||
|
CES-EX-GB-02-120
|
T4A
|
T4A
|
T4A
|
88°C
|
|||
|
CES-EX-GB-02-100
|
T5
|
T5
|
T4A
|
88°C
|
|||
|
CES-EX-GB-02-80
|
T4A
|
T4
|
T4
|
87°C
|
|||
|
CES-EX-GB-02-60
|
T5
|
T4A
|
T4A
|
87°C
|
|||
|
CES-EX-GB-02-40
|
T5
|
T4A
|
T4A
|
80°C
|
|||
|
CES-EX-GB-02-30
|
T6
|
T5
|
T5
|
80°C
|
|||
Details Images
Application
Indonesia
- Explosion Proof LED Flood Light
- Explosion Proof LED Flood Light
Netherlands - Seaside Oil Refinery
CESP LED Explosion proof Lights
for Powder Magazine in Chile
for Powder Magazine in Chile
Natural Gas Hanling Facility in Malaysia- 120W Led EX-proof Light Project
Australian Gas Station Lighting - CES-J100
CES-J series is used for
Oil depot lighting
WIDE APPLICATIONS
CES-EX-LN-02P
CNOOC -
China National Offshore Oil Corporation Lighting Engineering Project.
CES-EX-LN-02P Linear Light replace to the ex-proof fluorescent light in Singapore
Control Room - United States
CES-EX-LN-02P Ex-Proof Linear Light
CES-EX-LN-02P Ex-Proof Linear Light
Italy - these luminaries are installed in explosion-proof boxes
