Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Gangyuan
-
Model Number:
-
KAN0241H-0350C
-
Color:
-
White
-
protaction level:
-
high level
-
Dimension::
-
4.1x1.8mm
-
height:
-
2.8-3.5mm
-
Sample:
-
free
-
Life expectancy:
-
100, 000
-
Action Type:
-
Top push
-
Operating force:
-
100gf/160gf/260gf±50gf
-
Feature:
-
Dust proof switches
-
Certification:
-
other
Quick Details
-
Protection Level:
-
High level
-
Max. Current:
-
50mA
-
Max. Voltage:
-
12V DC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Gangyuan
-
Model Number:
-
KAN0241H-0350C
-
Color:
-
White
-
protaction level:
-
high level
-
Dimension::
-
4.1x1.8mm
-
height:
-
2.8-3.5mm
-
Sample:
-
free
-
Life expectancy:
-
100, 000
-
Action Type:
-
Top push
-
Operating force:
-
100gf/160gf/260gf±50gf
-
Feature:
-
Dust proof switches
-
Certification:
-
other
Products Description
|
Type
|
Tact Switch
|
|
Operating force
|
1.57±0.5N
|
|
Operating Temperature Range
|
5°C-35°C
|
|
Low resistance
|
-30±2°C
|
|
Heat resistance
|
80±2°C
|
|
Salt mist
|
8h±1h
|
|
Operation life
|
100,000
|
|
Full travel
|
0.2±0.1mm
|
|
Return force
|
0.4N MIN
|
|
Sulfuration resistance
|
72h
|
