Quick Details
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
HITREES
-
Dimension(L*W*H):
-
depended
-
Weight:
-
2000 KG
-
Product name:
-
Fishery indusry equipment plate freezer for shrimp
-
Eva. Area:
-
30-91m2
-
Plate material:
-
Aluminum Alloy
-
Refrigerant:
-
R404A
-
Size of Block:
-
customized
-
Plate Pitches:
-
58-108mm
-
Qty of Plates:
-
9-36
-
Outlet Temperature:
-
-35℃
-
Freezing time:
-
approx 200min
-
Refrigeration consumption:
-
20-80kw
Quick Details
-
Voltage:
-
Customized
-
Power:
-
1500
-
Cooling Capacity:
-
720-2600kg/batch
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
HITREES
-
Dimension(L*W*H):
-
depended
-
Weight:
-
2000 KG
-
Product name:
-
Fishery indusry equipment plate freezer for shrimp
-
Eva. Area:
-
30-91m2
-
Plate material:
-
Aluminum Alloy
-
Refrigerant:
-
R404A
-
Size of Block:
-
customized
-
Plate Pitches:
-
58-108mm
-
Qty of Plates:
-
9-36
-
Outlet Temperature:
-
-35℃
-
Freezing time:
-
approx 200min
-
Refrigeration consumption:
-
20-80kw
Product Overview
Vertical plate freezer bulk freezes
Vertical plate freezer
is used for fast freezing seafood,meat solid,high liquid content or water based solids,
fruit juices
and
fruit pulps in bulk
on land or on vessel.Products are simply placed or poured into vertical pockets between aluminum freezing plates. After freezing,the blocks can be unloaded by defrosting and lifting the products,within minutes the cycle can begin again.
PRODUCT SPECIFICATIONS
|
Freezing capacity
(kg/batch)
|
Size of plate
(mm)
|
Tier pitch
(mm)
|
Refrigerant
|
Total motor power
(kw)
|
Overall Dimention
(mm)
|
|
600
|
1060x530
|
75
|
R717/R507a
/R22/R404a
|
29
|
2500x1500x1200
|
|
800
|
|
75
|
|
38
|
3000x1500x1200
|
|
1000
|
|
75
|
|
47
|
3500x1500x1200
|
|
1280
|
|
75
|
|
61
|
4300x1500x1200
|
|
600
|
|
100
|
|
29
|
2500x1500x1200
|
|
800
|
|
100
|
|
38
|
3000x1500x1200
|
|
1000
|
|
100
|
|
47
|
3500x1500x1200
|
|
1300
|
|
100
|
|
62
|
4300x150
|
Detailed Images
1) Stainless steel cylinder and long lasting hoses
2) High strength galvanized frame.
1) Aluminum alloy extrusion plates, Hugeian and long lasting.
2)
Easy to clean and meet hygiene requirements
Packing & Delivery
Our Company
FAQ
Q1: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.
Q2: What's the lead time？
A: According to the order quantity, small order usually need 40-45 days, big order need negotiation.
Q3: What's your warranty terms?
A: We supply 12 months warranty time.
Q4: What's your payment terms?
A: We receive L/C D/A D/P T/T Western Union MoneyGram
