Quick Details
-
Brand Name:
-
Shanghai DongMeng
-
Dimension(L*W*H):
-
2692*1640*2350mm
-
Weight:
-
10 KG
-
After-sales Service Provided:
-
Overseas service center available
-
instation:
-
engineers to guide
-
model:
-
DMC1160
-
max feed size:
-
180mm
-
motor power:
-
132kw
-
closed side setting:
-
13-38mm
-
capacity:
-
115-260t/h
-
weight:
-
15.5T
-
factory history:
-
since 2000
Quick Details
-
Application:
-
Mining Quarry Road Building Construction
-
Capacity(t/h):
-
50-800tons/hour
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Shanghai DongMeng
-
Dimension(L*W*H):
-
2692*1640*2350mm
-
Weight:
-
10 KG
-
After-sales Service Provided:
-
Overseas service center available
-
instation:
-
engineers to guide
-
model:
-
DMC1160
-
max feed size:
-
180mm
-
motor power:
-
132kw
-
closed side setting:
-
13-38mm
-
capacity:
-
115-260t/h
-
weight:
-
15.5T
-
factory history:
-
since 2000
Main Technical Parameters:
| Model | Chamber | Max.feed size(mm) | Min discharge opening(mm) | Motor power (kw) | Capacity(th) | Weight |
| DMC1000 | C/M/F/EF | 160/115/80/50 | 13/10/8/6 | 110 | 50-235 | 10.8/10.51 |
| DMC1160 | C/M/F/EF | 180/130/90/60 | 13/10/10/6 | 132 | 60-260 | 15.5 |
| DMC1300 | C/M/F/EF | 200/150/102/70 | 16/13/10/8 | 200 | 88-390 | 22.3 |
| DMC1380 | C/M/F/EF | 215/160/115/76 | 19/16/13/8 | 220 | 11-440 | 26.3 |
| DMC1650 | C/M/F/EF | 235/175/130/90 | 22/19/13/10 | 250 | 148-580 | 36.5 |
| DMC1950 | C/M/F/EF | 350/203/140/95 | 22/16/13/10 | 280-315 | 180-725 | 44.3 |
| DHP200 | C/M/F | 185/125/95 | 22-38/16-32/13-26 | 160 | 95-225 | 10.9 |
| DHP300 | EC/C/M/F | 230/211/150/107 | 26-51/22-45/16-38/13-32 | 220 | 110-400 | 17.8 |
| DHP400 | EC/C/M/F | 300/250/200/120 | 32-51/26-51/22-45/16-38 | 315 | 237-570 | 25 |
| DHP500 | EC/C/M/F | 335/280/210/133 | 32-51/26-51/22-45/16-38 | 400 | 370-884 | 34.1 |
Delivery for Stationary crushing plant
1) Pre-sale service:
Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service:
Accompany you to complete the acceptance of the equipment,draft the construction scheme and
detailed process, and complete process of export.
3) After-sales service:
We sent engineer to the scene to guide installation, debugging and training operators.
4) Service supervision:
Any dissatisfaction on service attitude, service skills, quality and morality of our technical staff , please feel free to contact us by
dialing 24 hours hot line:0086-21-68911957.
