Quick Details
-
Size:
-
12500*2500*1550
-
Place of Origin:
-
Shandong, China
-
Axle Brand:
-
13TON Axle FUWA Brand
-
twist lock No:
-
4/8/12pcs
-
Usage:
-
20ft,30ft,40ft,45ft,48ft container transport
-
Suspension:
-
Mechanical/Air suspension
-
Landing Gear:
-
Standard 28Ton
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Brake System:
-
Dual Line Braking System
-
Electric:
-
24V 7 ways
-
Color:
-
Customers Optional
-
OE NO.:
-
Flatbed Container Trailer
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
50ton
-
Brand Name:
-
AOTONG
-
Size:
-
12500*2500*1550
-
Place of Origin:
-
Shandong, China
-
Axle Brand:
-
13TON Axle FUWA Brand
-
twist lock No:
-
4/8/12pcs
-
Usage:
-
20ft,30ft,40ft,45ft,48ft container transport
-
Suspension:
-
Mechanical/Air suspension
-
Landing Gear:
-
Standard 28Ton
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Brake System:
-
Dual Line Braking System
-
Electric:
-
24V 7 ways
-
Color:
-
Customers Optional
-
OE NO.:
-
Flatbed Container Trailer
JUYUAN truck 40ft flat bed semitrailer use 3 axles plat form shipping container trailer for sale
WELCOME TO JUYUAN
|
Product Information |
|||||
|
Product |
Flatbed or skeleton type trailer |
|
|||
|
Brand Name |
Aotong Brand |
||||
|
Announcement (batch) |
229 |
||||
|
Place of Origin |
Shandong province, China |
||||
|
Color |
Any color will be available |
||||
|
Manufacturer |
Shandong JUYUAN Automobile Technology Co., Ltd |
||||
|
Specifications |
|||||
|
Parameter |
|||||
|
Outside Dimensions (L*W*H) |
(6000-17000)*2500*1550mm |
||||
|
Rated Load |
45000 kg |
||||
|
Tare Weight |
7000 kg |
||||
|
Wheel Base |
8390+1310+1310 (mm) |
||||
|
Twist lock No |
12 |
||||
|
Running Gear |
|||||
|
Tires |
specification |
12R22.5-18 |
|||
|
No. of tires |
8/12/16 |
||||
|
Spare tire carriers |
1 or 2 |
||||
|
Axles
|
Brand |
FUWA (BPW optional) |
|||
|
No. of axles: |
2/3/4 |
||||
|
Axle-load |
13000kg |
||||
|
Wheel rim |
7.50-20 rim or 8.00 |
||||
|
Suspension |
rigid suspension,10 pcs leaf-spring |
||||
|
Brakes |
brand |
TKL brand |
|||
|
Brake chamber |
double air chamber |
||||
|
System |
Dual line braking system /ABS |
||||
|
Under Frame |
|||||
|
Departure Angle |
16 |
||||
|
Front/Rear Overhang |
1890mm |
||||
|
Main Beam |
material |
I beam ,Q345B, automatic submerged arc welded |
|||
|
specification |
Height is 500mm,upper plate is 14mm,lower plate is 16mm,middle is 8mm |
||||
|
Cross Beam material |
Q235B |
||||
|
Side beam |
Channel steel |
||||
|
Plate form |
Steel Sheet 3mm thickness or diamond plate(Also can choose other thickness ,such as 2mm,2.3mm,4mm,5mm,6mm) |
||||
|
King Pin |
50# or 90# |
||||
|
Landing gear |
28Ton |
||||
|
Accessory |
One tooling box with a set of standard trailer tool |
||||
|
Electrical |
|||||
|
Voltage |
24V |
||||
|
Receptacle |
7 ways (7 wire harness) |
||||
|
Lights |
Front corner marker lamp :red ;reflector lamp :white |
||||
|
Side marker :orange |
|||||
|
Rear lamp :red; rear reflector :white; turn single lamp :orange |
|||||
|
Painting ,marking and side guard can according to the customer’s requirement |
|||||
We transport the semi trailers by bulk or container. Our factory possesses long-term cooperation with ship agency which can provide you lowest shipping fee.
MORE DETAILS
Functions :
1. This series flatbed and skeleton continer semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as container transportin
2. The capacity is for 20ft,30ft,40ft,45ft,48ft,53ft containers, we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs
Detail process:
1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.
1. Can i have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.
2. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.
3. Can i customize the painting and the trailer design?
Yes, we offer customized design and logo for reasonable type.
4. What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight
5.How do you ensure its quality?
We are direct factory and we have professional quality inspector.We will not let any imperfections departure from our factory.
6.Can you provide the certificate we need?
Yes,We can provide the certificate you need,such as FORM E,Certificate of origin,CNCA,SONCAP,ASME,DOT,ECE as so on.
FACTORY & PRODUCTS
We are direct manufacturer and we have strong producing capacity and R&D capacity! Our raw material and OEM parts including axle, suspension, tyre, are purchased centralizedly by famous brand , every node will be inspected strickly. Moreover, advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding qulity.
