Quick Details
-
Brand Name:
-
SHD
-
Dimension(L*W*H):
-
5262*1916*1916
-
Capacity:
-
5-200M3
-
Weight:
-
4800
-
Inner Material:
-
q345r
-
Outer Material:
-
antiseptic painting
-
Design Pressure(MPa):
-
2.16, 2.16
-
Design Standard:
-
GB
-
Working Temperature(℃):
-
-20 - 40 ℃
-
Color:
-
white
-
size:
-
customized
-
The material:
-
Inner S30408 Outer 16MnDr
-
logo:
-
Accept Customized Logo
-
Standard:
-
GB150/ASME
-
Brand name:
-
HNJS
-
Service life:
-
20years
Quick Details
-
Volume (m³):
-
5-200M3
-
Max Working Pressure(MPa):
-
1.6 MPa
-
Place of Origin:
-
Henan, China, China
-
Brand Name:
-
SHD
-
Dimension(L*W*H):
-
5262*1916*1916
-
Capacity:
-
5-200M3
-
Weight:
-
4800
-
Inner Material:
-
q345r
-
Outer Material:
-
antiseptic painting
-
Design Pressure(MPa):
-
2.16, 2.16
-
Design Standard:
-
GB
-
Working Temperature(℃):
-
-20 - 40 ℃
-
Color:
-
white
-
size:
-
customized
-
The material:
-
Inner S30408 Outer 16MnDr
-
logo:
-
Accept Customized Logo
-
Standard:
-
GB150/ASME
-
Brand name:
-
HNJS
-
Service life:
-
20years
|
Actual Volume (m3)
|
Max Working Pressure (Mpa)
|
Empty Container (kg)
|
Overall Dimensions (diameter*height)
|
|
5
|
0.6
|
3623
|
1916*5260
|
|
|
0.8
|
3825
|
|
|
|
1.6
|
5118
|
|
|
|
0.6
|
5790
|
2316*5970
|
|
10
|
0.8
|
6235
|
|
|
|
1.6
|
10710
|
|
|
|
2.0
|
13200
|
|
|
30
|
0.6
|
13527
|
2720*10230
|
|
|
0.8
|
15100
|
|
|
|
1.6
|
18110
|
|
|
50
|
0.6
|
18650
|
3020*12670
|
|
|
0.8
|
21565
|
|
|
|
1.6
|
26740
|
|
|
100
|
0.6
|
36570
|
3524*17040
|
|
|
0.8
|
44595
|
|
|
|
1.6
|
53550
|
|
|
150
|
0.6
|
60878
|
3928*20210
|
|
|
0.8
|
72365
|
|
|
|
1.6
|
88663
|
|
|
200
|
0.6
|
76838
|
4724*19192
|
|
|
0.8
|
92143
|
|
|
|
1.6
|
108440
|
|
