We have different types of excavators, we will recommend a suitable machine for you according to the model and configuration
requirements provided.
- Product Details
- {{item.text}}
Quick Details
-
Power:
-
20Kw
-
Place of Origin:
-
CHINA SHANDONG
-
Brand Name:
-
LEHMAN
-
Maximum Digging Height:
-
2900mm
-
Maximum Digging Depth:
-
2150mm
-
Machine Weight:
-
1800 kg
-
Max Digging Radius:
-
2500mm
-
Track width:
-
200mm
-
Track Length:
-
1500mm
-
Bucket Width:
-
400mm
-
Transport length:
-
2300mm
-
Unloading Height:
-
2200mm
-
Overall Height:
-
2150mm
-
Ground clearance:
-
380mm
-
wheel pitch:
-
770mm
-
Chassis width:
-
1100mm
-
Rotary radius:
-
1190mm
Quick Details
-
Operating Weight:
-
2.0ton
-
Bucket capacity:
-
0.045m3
-
Engine Brand:
-
Changchai 390
-
Power:
-
20Kw
-
Place of Origin:
-
CHINA SHANDONG
-
Brand Name:
-
LEHMAN
-
Maximum Digging Height:
-
2900mm
-
Maximum Digging Depth:
-
2150mm
-
Machine Weight:
-
1800 kg
-
Max Digging Radius:
-
2500mm
-
Track width:
-
200mm
-
Track Length:
-
1500mm
-
Bucket Width:
-
400mm
-
Transport length:
-
2300mm
-
Unloading Height:
-
2200mm
-
Overall Height:
-
2150mm
-
Ground clearance:
-
380mm
-
wheel pitch:
-
770mm
-
Chassis width:
-
1100mm
-
Rotary radius:
-
1190mm
WELCOME TO LEHMAN FACTORY
FACTORY ORDERS, SUPPORT ALL KINDS OF CUSTOMIZATION, CUSTOMIZE THE DESIGN YOU WANT！
Machine supports CE EURO 5 certification EPA Engine
2-Year Machine Warranty Service Has Been Opened!
Send inquiry Contact Supplier For Exclusive Services And Preferential Price
Products Description
|
Model
|
L10
|
L16
|
L17
|
L20
|
|
Operating Weight
|
1,000 kg
|
1,400 kg
|
1,700 kg
|
2,000 kg
|
|
Rated Power
|
8.9 kw (12 hp)
|
19 kw (26 hp)
|
29 kw (39 hp)
|
20 kw (27.2 hp)
|
|
Engine Brand
|
KOOP
|
LAIDONG
|
LAIDONG
|
CHANGCHAI
|
|
Max. Digging Depth
|
1,500 mm
|
1,800 mm
|
1,900 mm
|
2,150 mm
|
|
Max. Digging Height
|
2,500 mm
|
2,590 mm
|
2,820 mm
|
2,950 mm
|
|
Overall Dimension
|
2,200*940*2,150
|
2,550*1,100*2,200
|
2,550*1,100*2,200
|
2,400*1,150*2,200
|
OUR MINI EXCAVATOR Features:
1. Excavators with compact dimensions can easily drive through narrow passages and doors.
2. Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
3. Powerful engine andperfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
4. Bucket hoses are well protected within the boom and the cylinder is mounted above the structure.
5. The operator area is spacious and laid out to provide comfort and ease of operation.
6. Excellent engine provides excellent power with minimal fuel use for more productivityper tank.
Optional Attachment
