Quick Details
-
Power:
-
Manual
-
Min. Lifting Height:
-
2050mm
-
Table Size:
-
600*700mm
-
Overall Dimensions:
-
820*820*2050mm
-
Weight:
-
125 kg
-
Operation Mode:
-
Manual
-
Side Support Legs:
-
Two
-
Self Lock For Lifting:
-
Yes
-
Inclinable:
-
Yes
-
Lifting Height:
-
2000-7900mm
-
Support Wheels:
-
PU
-
Side Wheels:
-
Nylon
-
Inclinable Wheels:
-
Rubber
-
Color:
-
Yellow, Orange, Blue,Customized
-
Certification:
-
CE ISO9001
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SAGA FIRST
-
Power:
-
Manual
-
Min. Lifting Height:
-
2050mm
-
Table Size:
-
600*700mm
-
Overall Dimensions:
-
820*820*2050mm
-
Weight:
-
125 kg
-
Operation Mode:
-
Manual
-
Side Support Legs:
-
Two
-
Self Lock For Lifting:
-
Yes
-
Inclinable:
-
Yes
-
Lifting Height:
-
2000-7900mm
-
Support Wheels:
-
PU
-
Side Wheels:
-
Nylon
-
Inclinable Wheels:
-
Rubber
-
Color:
-
Yellow, Orange, Blue,Customized
-
Certification:
-
CE ISO9001
Light Weight Portable Electric Hydraulic Aluminum Material Lifting Platforms
- OEM & ODM Service -
|
Model Type |
LGA- 35 |
LGA-50 |
LGA-65 |
LGA-79 |
|
Lifting Height(m) |
3.5 |
5 |
6.5 |
7.9 |
|
Load Capacity(kg) |
340 |
320 |
300 |
280 |
|
Fork Size(m) |
0.6*0.7 |
0.6*0.7 |
0.6*0.7 |
|
|
Net Weight(kg) |
145 |
170 |
190 |
210 |
|
Overall Length(m) |
1.48 |
1.48 |
1.48 |
|
|
Overall Width(m) |
0.82 |
0.82 |
0.82 |
|
|
Overall height(m) |
2.1 |
2.1 |
2.1 |
|
|
Operation |
manual |
manual |
manual |
SAGA FIRST Aluminum LIfting Platforms are high-quality lifting platform with capacity 300kg, the lifting height 2m-7.9m. Aluminum lifting platforms are equipped with forks which can lift pallets,cargo boxes and so on.
Compact structure makes the manual aluminum lift very useful for warehouse lifting cargos.
Aluminum LIfting Platforms is famous for its light weight and high lift with forks. Aluminum LIfting Platforms are widely use in outdoors and indoors working, such as warehouse, home, hotel, airport and so on. It becomes a ideal equipment for aerial working.
1. Manual Lifting,No Need Electric Power. Suitable For Places Where Electric Power is Unavailable.
2. Made by aluminum alloy material, light weight is suitable for one man operation.
3. Special aluminum mast and roller device between the mast. the stability is good.
4. Support legs structure of dual protection, make the working more security.
5. Equipped With Inclined Side Wheels And Can be Put Down On Truck For Easy Transportation.
6.Adopting The Working Principle of Pulley And Reduce The Man Power Greatly.
Aerial Work Platforms is widely used for the equipment installations and maintenance such as construction sites workshops, warehouse, granary, theatre or museum, bus/railway stations, hotels, airports, gas station and aerial pipeline. Non-trace universal polyurethane wheels used will be no damage to ground. AC power or battery power make the low noise when using.
All of Aerial Work Platforms are approved by European certificates and meet the international standards.
|
Questions |
Answers |
|
Are you a factory or trading company? |
We're factory with over 12years exporting experience. |
|
What's the MOQ? |
1UNIT,the more,the better. |
|
What's the payment terms? |
<USD4999: 100%TT in advance. >USD5000: 30%TT in advance,balance before shipment. >USD100,00: TT or Irrevocable L/C At Sight. |
|
Do you offer OEM&ODM service? |
Yes,like lifting capacity, lifting height, size of platform,painting color,logo,manual etc. |
|
What's the delivery time? |
15~20days after down payment |
|
What's the quality warranty? |
24 months.Offer free parts for replacement. |
|
How can I get the after-sales service? |
We offer videos,pictures and technical guidance immediately. |
|
What's your QA&QC policy? |
3times 100% inspection before shipping. |
|
Can you tell me your clients in my country? |
Of course. But only after the permittance of customers. |
